EATON E50DH1 Limit Switch Head, Side, Push Button Actuator
Item: BJ2ZURModel: E50DH1Cross Ref: 49C025
7 In Stock
Ships within 2 days via
10.00% off
€451.11 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Limit Switch |
| Action | Maintained |
| Actuator Location | Side |
| Actuator Style | Plunger |
| Actuator Type | Side maintained Pushbutton |
| Arm Length - Maximum | 0.2" |
| Arm/operator Length | 0.2" |
| Compatible With Brand | Eaton |
| Compatible With Grainger Part Number | 49A973 |
| Compatible With Manufacturer Model Number | E50SA |
| Compatible With Series | E50 Series |
| Differential Travel | 0.32" |
| Directional Movement | Linear |
| Display Qty | 1 |
| Enclosure Material | Die Cast Zinc |
| Height | 3.33" |
| Includes Actuator | Actuator Included |
| Ip Rating | IP67 |
| Length | 1.05" |
| Manufacturer Warranty Length | 1 yr. |
| Max. Operating Temp. | 201°F |
| Min. Operating Temp. | 14°F |
| Nema Enclosure Rating | NEMA 1, NEMA 13, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P |
| Operating Force | 2.2N |
| Operating Torque | 5 lbs.-in. |
| Overall Depth | 1.05" |
| Overall Height | 3.33" |
| Overall Width | 1.54" |
| Overtravel | 0.2" |
| Plunger Adjustability | Fixed |
| Pretravel | 0.13" |
| Reset Travel | 0.13" |
| Series | E50 Series |
| Total Travel | 0.32" |
| Warranty | 1 yr. |
| Width | 1.54" |
Shipping Info:
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 8.46 |
| Ship length (cm) | 2.67 |
| Ship width (cm) | 3.91 |
| Country of Origin | US |
Product Variants
| Product | Model | Ip Rating | Actuator Style | Contact Form | Ac Contact Rating | Electrical Connection | Height | Dc Contact Rating | Boot Sealed Actuator | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
E50AH16P | IP67, IP69K | Plunger | 1NO/1NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 250V | Boot Included | €890.12 | |
 |
E50AL1 | IP67 | Rotary Lever | 1NO/1NC | 10A @ 240V | Screw Terminals | 2.46" | 1A @ 250V | No Boot Included | €796.00 | |
|
E50AL16P | IP67, IP69K | Rotary Lever | 1NO/1NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 250V | Boot Included | €714.20 | |
|
E50AH1 | IP67 | Plunger | 1NO/1NC | 10A @ 240V | Screw Terminals | 4.22" | 1A @ 250V | No Boot Included | €883.35 | |
|
E50AM16P | IP67, IP69K | Rotary Lever | 1NO/1NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 125V | Boot Included | €801.59 | |
 |
E50AM1 | IP67 | Rotary Lever | 1NO/1NC | 10A @ 240V | Screw Terminals | 2.46" | 1A @ 250V | No Boot Included | €693.52 | |
|
E50AR1 | IP67 | Rotary Lever | 1NO/1NC | 10A @ 240V | Screw Terminals | 2.46" | 1A @ 250V | No Boot Included | €618.62 |
