EATON E50BS1 Heavy Duty Limit Switch, 2NC/2NO, 10A, 600V, 1.44 Inch Actuator Lg, Limit Switch, Linear
Item: BJ2ZTQModel: E50BS1Cross Ref: 49A982
7 In Stock
Ships within 2 days via
10.00% off
€763.87 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Limit Switch |
| Accuracy | Within 0.003 |
| Connection | Screw Terminal |
| Contact Configuration | 2 NO, 2 NC |
| Contact Rating | 10A At 240V AC, 1A At 250V DC |
| Enclosure Material | Die Cast Zinc |
| Height | 3" |
| Ip Rating | IP67 |
| Length | 4" |
| Max. Ac Amps | 10A |
| Max. Dc Amps | 1A |
| Max. Operating Temp. | 201°F |
| Min. Operating Temp. | 14°F |
| Nema Enclosure Rating | NEMA 1, NEMA 13, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P |
| Switch Type | Side pushbutton |
| Warranty | 1 yr. |
| Width | 1" |
Shipping Info:
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 7.62 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
Product Variants
| Model | Ip Rating | Actuator Style | Contact Form | Ac Contact Rating | Electrical Connection | Height | Dc Contact Rating | Boot Sealed Actuator | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| E50AW26P | IP67, IP69K | Wobble Stick | - | - | - | 5.38" | - | - | €857.30 | |
| E50AH16P | IP67, IP69K | Plunger | 1NO/1NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 250V | Boot Included | €890.12 | |
| E50AL16P | IP67, IP69K | Rotary Lever | 1NO/1NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 250V | Boot Included | €714.20 | |
| E50BL16P | IP67, IP69K | Rotary Lever | 2NO/2NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 125V | Boot Included | €1,073.15 | |
| E50BR16P | IP67, IP69K | Rotary Lever | 2NO/2NC | 10A @ 240V | 8 ft. Cable | 4.67" | 1A @ 250V | Boot Included | €914.27 | |
| E50AW16P | IP67, IP69K | Wobble Stick | - | - | - | 5.38" | - | - | €825.04 | |
| E50BW16P | IP67, IP69K | Wobble Stick | - | - | - | 5.38" | - | - | €1,150.70 |
