EATON E50BH16P Heavy Duty Limit Switch, 2NC/2NO, 10A At 600V, 1.44 Inch Actuator Length, Linear | CJ3VVK 49C008

EATON E50BH16P Heavy Duty Limit Switch, 2NC/2NO, 10A, 600V, 1.44 Inch Actuator Lg, Linear, Side

Item: CJ3VVKModel: E50BH16PCross Ref: 49C008
7 In Stock

Ships within 2 days via

€1,222.93
10.00% off
€1,100.63 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Limit Switch
Ac Contact Rating 10A @ 600V
Action Maintained
Actuator Length 1.44"
Actuator Length - Limit Switch 1 11/25"
Actuator Location Side
Actuator Location (limit Switch) Side
Actuator Style - Limit Switch Plunger
Arm Material Metal
Basic Actuator Style Plunger
Basic Actuator Style (limit Switch) Plunger
Body Configuration Plug In
Body Depth 1.58"
Body Height 3.13"
Body Height - Limit Switch 3.13"
Body Material Zinc
Body Material Type Metallic
Body Style (limit Switch) Standard
Body Style - Limit Switch Standard
Body Width 1.54"
Boot Sealed Actuator No Boot Included
Boot Sealed Actuator (limit Switch) No
Boot Sealed Actuator - Limit Switch No
Contact Form 2NO/2NC
Dc Contact Rating 1A @ 250V
Differential Travel 0.32"
Directional Movement Linear
Electrical Connection 8 ft. Cable
Includes Actuator Actuator Included
Ip Rating Ip67, Ip69
Limit Switch Style Heavy Duty Limit Switch
Mounting - Limit Switch Surface
Mounting Hole Diameter 1/5"
Mounting Hole Horizontal Center To Center Distance 59 mm
Mounting Hole Spacing - Limit Switch 2.34" x 1.16"
Mounting Hole Vertical Center To Center Distance 29 mm
Mounting Style Surface
Movement Linear
Nema Enclosure Rating NEMA 1, NEMA 13, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P
Number Of Mounting Holes 2
Operating Force - Maximum 5 lbf.
Operating Force - Minimum 8 ozf
Operating Temperature - Maximum 250°F
Operating Temperature - Minimum 14°F
Overall Depth 1.54"
Overall Height 4.22"
Overall Width 2 1/4"
Plunger Adjustability Fixed
Pretravel 0.13"
Reset Travel 0.13"
Resistance Properties Chemical Resistant
Series E50 Series
Stem Thread - Limit Switch No Stem
Total Travel 0.32"

Shipping Info:

Ship weight (kg) 0.59
Ship height (cm)2.54
Ship length (cm)2.54
Ship width (cm)2.54
Country of OriginMX

Product Variants

ProductModelIp RatingActuator StyleContact FormAc Contact RatingElectrical ConnectionHeightDc Contact RatingBoot Sealed ActuatorPrice
EATON E50AH16P E50 Heavy Duty Factory Sealed 6P+ Limit Switch, 8 Ft. Cable, 10A At 240 Vac | BJ2ZHN 49C004 E50AH16PIP67, IP69KPlunger1NO/1NC10A @ 240V8 ft. Cable4.67"1A @ 250VBoot Included€890.12
EATON E50AL1 E50 Nema Heavy Duty Plug-In Limit Switch, Assembly, Screw Terminals, 10A At 240 Vac | BJ2ZHQ 49A922 E50AL1IP67Rotary Lever1NO/1NC10A @ 240VScrew Terminals2.46"1A @ 250VNo Boot Included€796.00
EATON E50AL16P E50 Heavy Duty Factory Sealed 6P+ Limit Switch, 8 Ft. Cable, 10A At 240 Vac | BJ2ZHU 49A993 E50AL16PIP67, IP69KRotary Lever1NO/1NC10A @ 240V8 ft. Cable4.67"1A @ 250VBoot Included€714.20
EATON E50AH1 E50 Nema Heavy Duty Plug-In Limit Switch, Screw Terminals, 10A At 240 Vac, 1A At 250 Vdc | BJ2ZHX 49A921 E50AH1IP67Plunger1NO/1NC10A @ 240VScrew Terminals4.22"1A @ 250VNo Boot Included€883.35
EATON E50AM16P E50 Heavy Duty Factory Sealed 6P+ Limit Switch, 8 Ft.Cable, 10A At 240 Vac | BJ2ZKG 49A994 E50AM16PIP67, IP69KRotary Lever1NO/1NC10A @ 240V8 ft. Cable4.67"1A @ 125VBoot Included€801.59
EATON E50AM1 E50 Nema Heavy Duty Plug-In Limit Switch, Assembly, Screw Terminals, 10Aat240 Vac | BJ2ZKX 49A923 E50AM1IP67Rotary Lever1NO/1NC10A @ 240VScrew Terminals2.46"1A @ 250VNo Boot Included€693.52
EATON E50AR1 E50 Nema Heavy Duty Plug-In Limit Switch, Assembly, Screw Terminals, 10A At 240 Vac | BJ2ZMX 49A924 E50AR1IP67Rotary Lever1NO/1NC10A @ 240VScrew Terminals2.46"1A @ 250VNo Boot Included€618.62
