EATON CHSPT2SURGE Surge Protection Device, Single Phase, 120/240 VAC, 1000V L-L/600V L-G, L-N/800V N-G
Item: BJ8LFTModel: CHSPT2SURGECross Ref: 6YTP2
7 In Stock
Ships within 2 days via
10.00% off
€245.28 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Surge Protection Device |
| Amps | 15A |
| Basic Material | Nonmetallic |
| Color | Black |
| Depth | 2" |
| Enclosure Material | Advanced Polymer |
| Enclosure Nema Rating | 4 |
| Filtering | No |
| Height | 2" |
| Includes | 4 Self Tapping Screws |
| Interrupt Rating | 200 kAIC |
| Ip Rating | 56 |
| Length | 7 1/2" |
| Lightning Impulse Current | 36 kA |
| Max. Continuing Operating Voltage | 150/300V AC |
| Max. Operating Temp. | 122°F |
| Max. Surge Current Per Mode | 36 kA |
| Max. Surge Current Per Phase | 36 kA |
| Min. Operating Temp. | -40°F |
| Modes Of Protection | L G, L L, L N, N G |
| Modular | Yes |
| Mounting Style | Loadcenter |
| Nema Enclosure Rating | NEMA 4 |
| Nominal Discharge Current | 5 kA |
| Notes | 5 kA Nominal Discharge Current. Has 36 kA One Time Surge Current Rating. |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Operating Temperature | -40°C to 50°C |
| Operating Voltage | 150V L-N, 300V L-L |
| Phase | 1 |
| Protection Type | 700V L-N, 1200V L-L, 900V N-G, 700V L-G |
| Short Circuit Current Rating | 22 kA |
| Special Features | Meets Or Exceeds The Requirments Specified In IBC AA2006, CBC2007, And UBCAAZONE 4 |
| Surge Amps | 36 kA |
| System Connection | Parallel |
| Type | Surge Protection Device |
| Ul Spd Type | Type 2 |
| Voltage | 120/240V AC |
| Voltage Protection Rating | 1000V (L-L), 600V (L-G, L-N), 800V (N-G) |
| Voltage Rating | 120/240V |
| Warranty | Limited lifetime |
| Width | 5" |
| Wire Gauge | 14 AWG |
Shipping Info:
| Ship weight (kg) | 0.41 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 19.05 |
| Ship width (cm) | 12.7 |
| Country of Origin | US |
Product Variants
| Product | Model | Height | Max. Surge Current Per Phase | Nominal Discharge Current | Depth | Lightning Impulse Current | Max. Surge Current Per Mode | Amps | Phase | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
CHSPT2ULTRA | 2 1/2" | 108 kA | 20 kA | 2.5" | 108 kA | 108 kA | 50A | 1 | €515.30 |
