EATON C306GN3B Freedom Thermal Overload Relay, 60-79 A
Item: BJ8BNYModel: C306GN3BCross Ref: 243Y03
7 In Stock
Ships within 2 days via
10.00% off
€702.86 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Overload Relay |
| Amps | 60-79A |
| Auxiliary Contact Form | 1NO, 1NC |
| Body Depth | 5.25" |
| Body Height | 4.5" |
| Body Width | 4.5" |
| Design | NEMA, IEC |
| Frame Size | NEMA Size 1, 2, IEC Size G-K |
| Height | 4 1/2" |
| Length | 5 1/4" |
| Maximum Overload Relay Current Setting | 79A |
| Maximum Voltage Rating | 600V AC |
| Minimum Overload Relay Current Setting | 60A |
| Mounting | Panel |
| Nema Size | 1, 2 |
| Notes | Series B Overload Relays Have Load Lugs Built Into Relay Base And Will Only Accept Series B Heater Packs. These Relays Can Be Directly Attached To A Contactor Or They Can Be DIN Rail Or Panel Mounted Using An Adapter. |
| Number Of Poles | 3 |
| Overload Protection Type | Thermal |
| Phase | Three |
| Product Name | Eaton Freedom NEMA overload relay |
| Relay Mounting Style | Direct To Contactor |
| Relay Style | NEMA |
| Reset Type | Auto, Manual |
| Special Features | Heaters Required |
| Thermal Units Required | 3 Thermal (Heater) Units (Sold Separately) |
| Trip Class | 20 |
| Trip Type | Thermal |
| Type | Freedom NEMA |
| Warranty | Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first. |
| Width | 4 1/2" |
Shipping Info:
| Ship weight (kg) | 0.42 |
| Ship height (cm) | 11.43 |
| Ship length (cm) | 13.34 |
| Ship width (cm) | 11.43 |
| Country of Origin | US |
Product Variants
| Model | Number Of Poles | Trip Class | Height | Type | Amps | Body Height | Body Width | Body Depth | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| IQ504A | - | - | 4 1/2" | IQ 500 | 10.8-207A | - | - | - | - | RFQ
|
| IQ500LA | - | - | 4 1/2" | IQ 500 | 0.32-5.4A | - | - | - | €7,359.90 | |
| IQ502B | - | - | 4 3/5" | Freedom NEMA | 3.4-66A | - | - | - | €10,183.93 | |
| IQ500LB | - | - | 4 3/5" | Freedom NEMA | 0.32-5.4A | - | - | - | €9,897.98 | |
| IQ500M | - | - | 3 1/5" | IQ 500 | - | - | - | - | €6,006.72 | |
| IQ502A | - | - | 4 3/5" | IQ 500 | 3.4-66A | - | - | - | €9,897.98 | |
| JAM-TDAA | - | - | - | - | - | - | - | - | €32,290.24 |
