EATON 2606D56G19 Field Mount Replacement Shunt Trip, 120 VAC
€4,018.23 /unit
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Shunt Trip |
| For Use With | La, Lab, Hla Breaker |
| Frame Size | Frame J-K |
| Mounting Type | Right |
| Notes | 120V Suitable For 55% Pickup For Ground Fault Applications. Not Field Mountable On Non-Automatic Breakers/Molded Case Switches. Field Mounting Voids UL Listing Except On LA, HLA, MA, HMA, NB, HNB, PB, KB, HKB, KA, HKA, LB, HLB And Seltronic Breakers. |
| Special Features | G19 |
| Type | Field Mounting Shunt Trip |
| Voltage Rating | 120V |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
Shipping Info:
| Country of Origin | US |
