EATON 14101AF1013 Photoelectric Sensor, Distance 15 Feet, 300 mA Ac/Dc At 20-264VAC/15-30 VDC
Get it by Monday, Feb 16
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Photoelectric Sensor |
| Cable Sheath Material | PVC |
| Connection | 10 Ft (3 M) Cable |
| Contact Configuration | DC, NPN Open Collector AC, L1 Switched |
| Contact Rating | 300 MA AC/DC at 20-264V AC/15-30V DC |
| Cord Length | 120 ft. |
| Enclosure Lens Material | Polycarbonate |
| Enclosure Material | Structural Polyurethane Foam |
| Height | 2 16/25" |
| Input Voltage | 20-264V AC/15-30V DC |
| Ip Rating | IP68, IP69K |
| Led Indicator | Output Status, Red |
| Length | 0.47" |
| Max. Ac Amps | 300 mA |
| Max. Operating Temp. | 158°F |
| Maximum Dc Current | 300 mA |
| Nema Enclosure Rating | NEMA 1, NEMA 12, NEMA 13, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P |
| Operating Mode | Polarized Retroreflective |
| Operating Temperature - Min | -40°F |
| Product Name | Eaton Comet 18mm Tubular Photoelectric Sensor |
| Protection Type | Latching Short Circuit |
| Sensor Type | Polarized Retroreflective |
| Switch Type | Photoelectric |
| Warranty | 3 yrs. |
| Width | 0.71" |
Shipping Info:
| Ship weight (kg) | 0.13 |
| Ship height (cm) | 6.71 |
| Ship length (cm) | 1.19 |
| Ship width (cm) | 1.8 |
| Country of Origin | US |
Product Variants
| Model | Ip Rating | Operating Mode | Response Time | Sensing Method | Body Material | Price | |
|---|---|---|---|---|---|---|---|
| 13104AQD05 | IP68, IP69K | Background Suppression | - | - | - | €650.57 | |
| 13105ASROHS | IP68, IP69K | Background Suppression | - | - | - | €391.81 | |
| 13101ANS8126 | IP68, IP69K | Background Suppression | - | - | - | €804.56 | |
| 13101APS8126 | IP68, IP69K | Background Suppression | - | - | - | €408.97 | |
| 13104RS5072 | IP68, IP69K | Background Suppression | - | - | - | €371.21 | |
| 13104RS7290 | IP68, IP69K | Background Suppression | - | - | - | €1,034.34 | |
| 12100RF1217 | IP68, IP69K | Thru Beam | - | - | - | €282.09 |
