DEHN 929963 Data & Signal Surge Protective Device, 24VAC/VDC, Parallel Circuit, 2 Lines Or 1 Pair
Get it by Monday, Feb 16
€217.80 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Surge Protective Device |
| C2 Nominal Discharge Current (8/20 µs) Line-line (in) | 150A |
| C2 Nominal Discharge Current (8/20 µs) Line-pg (in) | 10 kA |
| C2 Total Nominal Discharge Current (8/20 µs) (in) | 10 kA |
| Capacitance Line-line (c) | Less Than Equal to 25 pF |
| Capacitance Line-pg (c) | Less Than Equal to 15 PF |
| China Compulsory Certification | CCC No. 2021312304001030 |
| Colour | Bare Surface |
| Connection | Connecting Lines 1.3 sq. mm |
| Csa & Usa Hazloc Approvals (2) | CSA 13.70000407 Class I Div 1, 2, Class I Zone 1 |
| Csa And Usa Hazloc Approvals (1) | CSA 13.70000407 EX IA [IA] IIC T5 T6 |
| Cut-off Frequency Line-line (fg) | 67 MHz |
| D1 Lightning Impulse Current (10/350 µs) Line-pg (iimp) | 1 kA |
| Degree Of Protection | Ip 67 |
| Earthing Via | Connecting Line |
| Enclosure Material | Stst (V4A) |
| For Mounting On (field / Device Side) Size | 1/2-14 NPT Male Thread |
| Iecex Approvals | Kem 09.0076X Ex Ia [Ia Ga] Iic T5, T6 Gb |
| Length Of The Connecting Lead | 250 mm |
| Max. Continuous Operating Voltage (a.c.) (uc) | 22.6V |
| Max. Continuous Operating Voltage (d.c.) (uc) | 32V |
| Max. Input Current Acc. To En 60079-11 (ii) | 0.55A |
| Max. Input Voltage Acc. To En 60079-11 (ui) | 30V |
| Nominal Current (il) | 0.55A |
| Nominal Voltage (un) | 24V |
| Operating Temperature Range (tu) | -50°C to +80°C |
| Product Datasheet | dehn-908013.pdf |
| Sil Classification | Up to Sil3 |
| Spd Class | T Class |
| Test Standards | Iec 61643-21, En 61643-21 |
| Voltage Protection Level Line-line At 1 Kv/µs C3 (up) | Less Than Equal to 50V |
| Voltage Protection Level Line-line For Inc2 (up) | Less Than Equal to 58V |
| Voltage Protection Level Line-pg At 1 Kv/µs C3 (up) | Less than Equal to 1200V |
| Voltage Protection Level Line-pg For Inc2 (up) | Less Than Equal to 1700V |
Shipping Info:
| Ship weight (kg) | 0.18 |
| HS code | 853630 |
| Country of Origin | DE |
