DAYTON 6RJY0 Indoor Duct Furnace 3704 Cfm Natural Gas 30 Degree F
Get it by Tuesday, Dec 23
10.00% off
€4,986.94 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Indoor Duct Furnace |
| Air Flow Rate | 3704 CFM |
| Air Temp. Rise | 30°F |
| Air Temp. Rise | 30 Degrees F |
| Btuh Input | 150,000 |
| Burner Air Inlet Size | 5 |
| Burner Air Inlet Size | 5" |
| Cfm @ 65 Deg. F Rise | 1500 CFM |
| Cfm @ 65(f) Rise | 1500 cfm |
| Cfm @ 80 Deg. F Rise | 1700 CFM |
| Cfm @ 80(f) Rise | 1700 CFM |
| Combustion Type | Separated Combustion |
| Depth | 40" |
| Features | Clamshell Style Heat Exchanger |
| Flue Dia. | 4" |
| Flue Diameter | 4" |
| Frequency | 60 Hz |
| Fuel Type | Natural Gas |
| Full Load Amps | 1.9A |
| Furnace Type | Power Vented Separated Combustion |
| Gas Connection | 1/2" |
| Gas Connection Size | 1/2" |
| Gas Connection Type | MNPT |
| Gas Type | Natural Gas |
| Heat Exchanger Gauge | 20 ga. |
| Heater Voltage | 115V AC |
| Heating Capacity Input | 150000 btuH |
| Heating Capacity Output | 120000 btuH |
| Heating Method | Fan Forced |
| Height | 36" |
| Ignition System | Direct Spark |
| Ignition Type | Direct Spark |
| Includes | Additional Safety Features Of Fan Time Delay, Air Flow Prove Switch, And Terminal Block Wiring |
| Indoor Air Discharge Height | 19" |
| Indoor Air Discharge Width | 18 1/4" |
| Indoor Air Discharge Width | 18-1/4" |
| Installation Height | 8 ft. |
| Manufacturers Warranty Length | 1 yr. |
| Max. External Sp | 1.81 in. wc |
| Max. External Sp | 1.81" WC |
| Maximum Amperage | 1.9A |
| Mounting Height | 8 ft. |
| Overall Depth | 40" |
| Overall Height | 36" |
| Overall Width | 20 5/8" |
| Primary Heat Exchanger Material | Aluminized Steel |
| Required Air Flow | 1233 CFM |
| Service Access Location | Bottom |
| Thermostat Included | No |
| Vent | Power |
| Vent Type | Power |
| Venting | Vented |
| Width | 20 5/8" |
Shipping Info:
| Ship weight (kg) | 84.6 |
| Ship height (cm) | 91.44 |
| Ship length (cm) | 101.6 |
| Ship width (cm) | 52.39 |
| HS code | 8416200040 |
| Country of Origin | US |
Product Variants
| Product | Model | Primary Heat Exchanger Material | Service Access Location | Overall Height | Overall Depth | Required Air Flow | Heating Capacity Input | Heating Capacity Output | Overall Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6RJV2 | Aluminized Steel | Bottom | 37 3/4" | 37" | 1389 CFM | 150000 btuH | 120000 btuH | 20 5/8" | €3,396.61 | |
|
6RJV9 | Stainless Steel | Bottom | 37 3/4" | 37" | 1389 CFM | 150000 btuH | 120000 btuH | 20 5/8" | €3,826.90 | |
 |
6RJW6 | Aluminized Steel | Side | 37 3/4" | 37" | 1389 CFM | 150000 btuH | 120000 btuH | 20 5/8" | €3,353.63 | |
|
6RJX3 | Stainless Steel | Side | 37 3/4" | 37" | 1389 CFM | 150000 btuH | 120000 btuH | 20 5/8" | €3,826.90 | |
|
6RJY7 | Stainless Steel | Bottom | 36" | 40" | - | 150000 btuH | 120000 btuH | 20 5/8" | €5,909.76 |
