DAYTON 6EAV8 Contactor Iec 25a 3p 24vac 1no
Item: AE8MMLModel: 6EAV8
7 In Stock
Ships within 2 days via
10.00% off
€137.43 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Contactor |
| Action Type | Non Reversing |
| Auxiliary Contacts Included | 1NO |
| Coil Volts | 24V AC |
| Contactor Style | IEC |
| Contactor Type | IEC |
| Depth | 3 3/4" |
| Embedded Surge Suppressor | No |
| Enclosure Nema Rating | No Enclosure |
| Enclosure Type | Open |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 25A |
| Full Load Amps-resistive | 40A |
| Full Load Current - Resistive | 40A |
| Height | 2 1/5" |
| Horsepower @ Single Phase - 120v Ac | 2 hp |
| Horsepower @ Single Phase - 240v Ac | 3 hp |
| Horsepower @ Three Phase (600 Vac) | 20 hp |
| Horsepower @ Three Phase - 208v Ac | 5 hp |
| Horsepower @ Three Phase - 480v Ac | 15 hp |
| Hp @ 1 Phase - 240v | 3 hp |
| Hp @ 3 Phase - 208v | 5 hp |
| Hp @ 3 Phase - 230v | 7 1/2 hp |
| Hp @ 3 Phase - 240v | 7 1/2 hp |
| Hp @ 3 Phase - 480v | 15 hp |
| Hp @ 3 Phase - 575v | 20 hp |
| Includes Auxiliary Contacts | Yes |
| Integrated Surge Suppression | No |
| Main Power Pole Contact Form | 3NO |
| Nema Enclosure Material | Not Applicable |
| Nominal Coil Voltage @ 60hz | 24V AC |
| Number Of Auxillary Contacts | 1 |
| Number Of Poles | 3 |
| Overall Depth | 3.75" |
| Overall Height | 2 1/5" |
| Overall Width | 2 1/5" |
| Reversible | No |
| Reversing Capability | Non-reversing |
| Standards | Csa, Ul Listed |
| Width | 2 1/5" |
| Wire Termination Type | Screw |
Shipping Info:
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 10.92 |
| Ship width (cm) | 9.4 |
| HS code | 8536410045 |
| Country of Origin | IN |
Product Variants
| Model | Reversing Capability | Auxiliary Contacts Included | Nominal Coil Voltage @ 60hz | Hp @ 3 Phase - 575v | Hp @ 3 Phase - 208v | Coil Volts | Hp @ 1 Phase - 240v | Reversible | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 6EAP7 | Non-reversing | 1NO/1NC | 24V AC | 30 hp | 10 hp | 24V AC | 5 hp | No | €280.58 | |
| 6EAP8 | Non-reversing | 1NO/1NC | 120V AC | 30 hp | 10 hp | 120V AC | 5 hp | No | €280.58 | |
| 6EAP9 | - | - | - | 30 hp | 10 hp | 240V AC | 5 hp | No | €280.58 | |
| 6EAR0 | Non-reversing | 1NO/1NC | 24V AC | 40 hp | 15 hp | 24V AC | 7 1/2 hp | No | €354.12 | |
| 6EAR1 | Non-reversing | 1NO/1NC | 120V AC | 40 hp | 15 hp | 120V AC | 7 1/2 hp | No | €354.12 | |
| 6EAR2 | Non-reversing | 1NO/1NC | 240V AC | 40 hp | 15 hp | 240V AC | 7 1/2 hp | No | €354.12 | |
| 6EAR3 | - | - | - | 50 hp | 20 hp | 24V AC | 10 hp | No | €397.19 |
