DAYTON 5Z548 Relay Magnetic Blowout DPDT 8 Pins 24VDC
Item: AE7LAWModel: 5Z548
7 In Stock
Ships within 2 days via
10.00% off
€58.49 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Open Power Relay |
| Body Depth | 3 2/5" |
| Body Height | 2 1/2" |
| Body Width | 2 1/2" |
| Coil Rating | Not Rated |
| Coil Voltage | 24V DC |
| Contact Amp Rating (resistive) | 40A @ 300V AC, 30A @ 28V DC |
| Contact Form | DPDT |
| Contact Material | Silver Cadmium Oxide |
| Contact Rating (ac) | 40A @ 300V |
| Contact Rating (dc) | 40A @ 28V |
| Electrical Connection | Screw |
| Electrical Connection - Power Relay | Screw |
| Electrical Connection Type | Screw |
| Features | Magnetic Blowout |
| Hp @ 120v | 1 1/2 hp |
| Mfr. Series | Dayton Power Series |
| Mounting | Panel |
| Number Of Pins | 8 |
| Number Of Pins - Relay | 8 |
| Number Of Pins/terminals | 8 |
| Number Of Poles | 2 |
| Overall Depth | 2 1/2" |
| Overall Height | 2 1/2" |
| Power Consumption | 4 W |
| Power Consumption - Relay | 4 W |
| Push-to-test Button | No Test Button |
| Relay Mounting | Surface |
| Relay Mounting Style | Surface |
| Status Indicator | No Indicator |
Shipping Info:
| Ship weight (kg) | 0.29 |
| Ship height (cm) | 5.84 |
| Ship length (cm) | 8.38 |
| Ship width (cm) | 6.35 |
| HS code | 8536410050 |
| Country of Origin | CN |
Product Variants
| Product | Model | Number Of Pins/terminals | Coil Voltage | Contact Form | Hp @ 120v | Number Of Pins | Coil Rating | Contact Amp Rating (resistive) | Hp @ 240v | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1EGB2 | 8 | 24V DC | DPDT | 1 1/2 hp | 8 | 10 VA | 40A @ 277V AC, 40A @ 28V DC | 1 1/2 hp | €91.08 | |
 |
5X851 | 4 | 240V AC | SPST-NO | 2 hp | 4 | Not Rated | 40A @ 300V AC, 30A @ 28V DC | 2 hp | €43.96 | |
|
5YZ79 | 4 | 24V DC | SPST-NO | 2 hp | 4 | Not Rated | 40A @ 300V AC, 30A @ 28V DC | 2 hp | €43.96 | |
 |
5Z542 | 5 | 120V AC | SPDT | 1 1/2 hp | 5 | Not Rated | 40A @ 300V AC, 30A @ 28V DC | Not Rated | €128.64 | |
|
5Z552 | 5 | 12V DC | SPDT | 1 1/2 hp | 5 | Not Rated | 40A @ 300V AC, 30A @ 28V DC | Not Rated | €128.64 | |
|
5Z554 | 5 | 24V DC | SPDT | 1 1/2 hp | 5 | Not Rated | 40A @ 300V AC, 30A @ 28V DC | Not Rated | €131.96 |
