DAYTON

DAYTON 4VCR3 Drum Pump Discharge Tube 96 inch Length

Item: AD9VHZModel: 4VCR3

Check Availability

In Stock

Get it by Tuesday, Dec 23

~~€306.55~~

10.00% off

€275.90 /unit

Add To Cart

Request a Quote

Payment

Delivery

Product Specifications:

Item	Hand Operated Drum Pump
Action Type	Rotary
Adapter Dia.	2"
Adapter Material	Cast Iron
Adapter Size	2"
Application	Oil Based Media, Diesel, Kerosene, Non Corrosive Media
Bung Connection Dia.	2"
Compatible Chemicals	Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, Kerosene, Motor Oil
Discharge	0-10 GPM
Discharge Tube Inside Dia.	3/4"
Discharge Tube Length	96"
Discharge Tube Outlet I.d.	3/4"
Discharge Tube Outlet Id Size	3/4"
Discharge Tube Outlet O.d.	1 1/8"
Discharge Tube Outlet Od Size	1-1/8"
Discharge Tubing Finish	Zinc Plated
Discharge Tubing Hose Material	Neoprene
Discharge Tubing Material	Zinc Plated Steel, Neoprene Rubber Hose, Aluminium Nozzle
Discharge Tubing Material	Steel
Discharge Tubing Nozzle Material	Aluminum
Features	1. Industry Standard For Rotary Pumps, These Are By Far The Heaviest Duty, Ideal For Tough Outdoor Use In Extreme Weather Conditions, 2. Solid Cast Iron Construction, Fully CNC Machined To Close Tolerances, 3. Graphite Vanes Are Self-Lubricating And Non-W
Fits Container Size	16 gal. to 55 gal.
Flow Rate	10 GPM
For Container Size	15 gal., 30 gal., 55 gal.
For Container Type	Bucket, Drum, Pail
For Media Type	Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, Kerosene, Motor Oil
For Use On	16 To 55 Gal. Drums
For Use With	Diesel, Kerosene, Non Corrosive Media, Oil Based Media
Gasket Material	Paper
Height	9 1/2"
Hose Inside Dia.	3/4"
Hose Material	Neoprene
Hose Outside Dia.	1 1/8"
Housing Finish	Powder Coated
Housing Material	Cast Iron
Housing Material - Pumps	Cast Iron
Includes	3/4" x 8 ft. Anti-Static Rubber Hose, Nozzle And Nozzle Holder
Includes Bung Adapter	Yes
Includes Discharge Hose	Yes
Includes Nozzle	Yes
Includes Suction Tube	Yes
Inlet Type	FNPT
Length	10 7/8"
Max. Flow Rate	10 gal. @ 120 Strokes
Max. Flow Rate For Oil	7 GPM
Max. Gpm For Oil	7 GPM
Max. Head	10 ft.
Max. Pressure	10 psi
Max. Temp.	250°F
Max. Viscosity	2000 SUS
Metered	No
Not Recommended Chemicals	Antifreeze (Coolant), Deionized Water, Ethyl (Ethanol), Fertilizers, Fresh Water, Fungicides, Herbicides, Lithium Grease, Methyl Ethyl Ketone (Mek), Salt Water, Sodium Hypochlorite/Bleach (To 20%)
Nozzle Material	Aluminum
Nozzle Operation	Manual
Ounces Per Stroke	Up to 10 GPM
Overall Length	10 7/8"
Power Source	Hand Operated
Pump Body Material	Cast Iron
Pump Package Type	Unmetered Dispensing With Manual Shut-Off
Seal Material	Graphite
Self Priming	Yes
Self-priming	Yes
Suction Tube Length	18 3/16" to 34 1/2"
Suction Tube O.d.	1"
Suction Tube Outlet O.d. Size	1"
Suction Tube Outside Dia.	1"
Suction Tube Type	Telescopic
Wetted Material	Cast Iron, Graphite, Paper, Polypropylene, Steel
Wetted Materials	Acetal, Buna N, Cast Iron, Graphite, Paper, Steel

Shipping Info:

Ship weight (kg)	10.2
Ship height (cm)	19.56
Ship length (cm)	66.04
Ship width (cm)	25.4
HS code	8413200000
Country of Origin	IN

Product Variants

Model	Max. Viscosity	Includes Suction Tube	For Container Size	Diesel Exhaust Fluid Compatible	Includes Discharge Hose	Includes Nozzle	Includes Bung Adapter	Metered	Price
FR112A	1500 SUS	Yes	55 gal.	No	Yes	Yes	Yes	No	€363.48
2RUJ9	8000 SUS	Yes	55 gal.	-	No	No	Yes	No	€54.55
2RUK1	8000 SUS	Yes	55 gal.	-	No	No	Yes	No	€83.36
2RUK2	1500 SUS	Yes	15 gal., 30 gal., 55 gal.	-	Yes	Yes	Yes	No	€402.19
2UY12	3000 SUS	Yes	1L	-	Yes	No	Yes	No	€22.31
2UY14	3000 SUS	Yes	15 gal., 30 gal., 55 gal.	-	Yes	No	Yes	No	€53.82
38Y789	500 SUS	Yes	5 gal.	-	No	No	Yes	No	€5.78
