DAYTON 4VCR2 Drum Pump Discharge Tube 7 inch Length
Get it by Friday, Aug 28
€ 34,99 Flat Shipping + VAT € 34,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€226.73 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Hand Operated Drum Pump |
| Action Type | Rotary |
| Adapter Dia. | 2" |
| Adapter Material | Cast Iron |
| Adapter Size | 2" |
| Application | Oil Based Media, Diesel, Kerosene, Non Corrosive Media |
| Bung Connection Dia. | 2" |
| Compatible Chemicals | Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, Kerosene, Motor Oil |
| Discharge | 10 GPM |
| Discharge Tube Inside Dia. | 7/8" |
| Discharge Tube Length | 7" |
| Discharge Tube Outlet Id Size | 55/64" |
| Discharge Tube Outlet Inside Dia. | 7/8" |
| Discharge Tube Outlet Od Size | 1-3/64" |
| Discharge Tube Outlet Outside Dia. | 1" |
| Discharge Tubing Finish | Zinc Plated |
| Discharge Tubing Material | Steel |
| Discharge Tubing Material | Zinc Plated Steel |
| Features | 1. Industry Standard For Rotary Pumps, These Are By Far The Heaviest Duty, Ideal For Tough Outdoor Use In Extreme Weather Conditions, 2. Solid Cast Iron Construction, Fully CNC Machined To Close Tolerances, 3. Graphite Vanes Are Self-Lubricating And Non-W |
| Fits Container Size | 15 gal., 30 gal., 55 gal. |
| Flow Rate | 10 GPM |
| Flow Rate @ Rpm | 10 Gpm @ 120 Rpm |
| For Container Size | 15 gal., 30 gal., 55 gal. |
| For Container Type | Bucket, Drum, Pail |
| For Media Type | Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, Kerosene, Motor Oil |
| For Use On | 15, 30 And 55 Gal. Drums |
| For Use With | Diesel, Kerosene, Non Corrosive Media, Oil Based Media |
| Gasket Material | Paper |
| Height | 9 1/2" |
| Hose Inside Dia. | 1" |
| Hose Outside Dia. | 1 3/64" |
| Housing Finish | Powder Coating |
| Housing Material | Cast Iron |
| Housing Material-pumps | Cast Iron |
| Included | Bung & Discharge Spout, Telescopic Suction Tube |
| Included Bung Adapter | Yes |
| Included Discharge Hose | No |
| Included Nozzle | No |
| Included Spout | Yes |
| Included Suction Tube | Yes |
| Inlet Size | 3/4" |
| Inlet Type | FNPT |
| Length | 10 7/8" |
| Max. Flow Rate | 10 gal. @ 120 Strokes |
| Max. Flow Rate For Oil | 7 GPM |
| Max. Gpm For Oil | 7 GPM |
| Max. Head | 10 ft. |
| Max. Pressure | 10 psi |
| Max. Temp. | 250°F |
| Max. Viscosity | 2000 SUS |
| Metered | No |
| Not Recommended Chemicals | Antifreeze (Coolant), Deionized Water, Ethyl (Ethanol), Fertilizers, Fresh Water, Fungicides, Herbicides, Lithium Grease, Methyl Ethyl Ketone (Mek), Salt Water, Sodium Hypochlorite/Bleach (To 20%) |
| Ounces Per Stroke | 10 GPM @ 120 RPM |
| Outlet Material | Steel |
| Overall Length | 10 7/8" |
| Power Source | Hand Operated |
| Pump Body Material | Cast Iron |
| Pump Package Type | Basic Pump With Spout |
| Seal Material | Graphite |
| Self Priming | Yes |
| Self-priming | Yes |
| Suction Tube Length | 18 3/16" to 34 1/2" |
| Suction Tube Outlet O.d. Size | 1" |
| Suction Tube Outside Dia. | 1" |
| Suction Tube Type | Telescopic |
| Wetted Material | Acetal, Buna N, Cast Iron, Graphite, Paper, Steel , Cast Iron, Graphite, Polypropylene, Steel |
Shipping Info:
| Ship weight (kg) | 8.96 |
| Ship height (cm) | 20.57 |
| Ship length (cm) | 66.04 |
| Ship width (cm) | 25.15 |
| HS code | 8413200000 |
| Country of Origin | IN |
Product Variants
| Product | Model | Housing Material | For Container Size | Discharge Tube Outlet Outside Dia. | Hose Inside Dia. | Max. Viscosity | For Container Type | Action Type | Included Suction Tube | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
FR112A | Aluminum | 55 gal. | 7/8" | 3/4" | 1500 SUS | Drum | Rotary | Yes | €363.48 | |
 |
2RUJ9 | Polypropylene | 55 gal. | 5/8" | 1/2" | 8000 SUS | Drum | Piston | Yes | €71.77 | |
 |
2RUK1 | Nylon | 55 gal. | 1/2" | 1/2" | 8000 SUS | Drum | Piston | Yes | €125.49 | |
 |
2RUK2 | Aluminum | 15 gal., 30 gal., 55 gal. | 3/4" | 3/4" | 1500 SUS | Bucket, Drum, Pail | Lever | Yes | €474.66 | |
 |
2UY12 | Polypropylene | 1L | 1/4" | 1/4" | 3000 SUS | Jug | Piston | Yes | €24.17 | |
 |
2UY14 | PVC | 15 gal., 30 gal., 55 gal. | 1" | 1" | 3000 SUS | Bucket, Drum, Pail | Siphon | Yes | €66.20 | |
 |
38Y789 | Polyethylene | 5 gal. | 7/8" | 1/2" | 500 SUS | Bucket, Pail | Siphon | Yes | €7.36 |
