DAYTON 3FRF8 Blower 262 Cfm 230v 0.28a 2880 Rpm | AC9CZR

DAYTON 3FRF8 Blower 262 Cfm 230v 0.28a 2880 Rpm

Item: AC9CZRModel: 3FRF8
7 In Stock

Ships within 2 days via

€284.12
10.00% off
€255.71 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item OEM Blower
Airflow @ 0.000 In Sp 262 CFM
Airflow @ 0.100 In Sp 212 CFM
Airflow @ 0.200-in. Sp 198 CFM
Airflow @ 0.250 In Sp Not Applicable
Amps 0.28A
Assembly Assembled
Bearing Type Ball
Blower Conduit Box No
Blower Item Low Profile Blower
Blower Outlet Shape Rectangular
Blower Wheel Diameter 2 15/16"
Blower Wheel Width 3 3/4"
Cfm @ 0.000-in. Sp 262
Cfm @ 0.100-in. Sp 212
Cfm @ 0.200-in. Sp 198 CFM
Conduit Box No
Current 0.28A
Dimension A 3 5/8"
Dimension B 4 13/16"
Dimension C 4 7/16"
Dimension D 1 3/4"
Dimension E 8 15/16"
Dimension F 4 3/4"
Dimension G 3 3/8"
Dimension H 14 3/4"
Dimension J 5/16"
Drive Type Direct Drive
For Ventilation Type Exhaust
Full Load Amps 0.28A
Housing Color Black
Housing Depth 4 2/5"
Housing Finish Flat
Housing Height 4 4/5"
Housing Material Steel
Housing Material Finish Flat
Housing Width 3 3/5"
Hz 50/60 Hz
Includes 6 Rubber Isolator
Inlet Dia. 2 9/16"
Inlet Diameter 2 1/2"
Lead Length 17"
Max. Ambient Temp. 104°F
Max. Inlet Temp. 104°F
Maximum Inlet Air Temperature 104°F
Maximum Static Pressure 0.75 in. wc
Motor Duty Class Continuous
Motor Enclosure Design Open
Motor Horsepower 1/40 hp
Motor Insulation Class B
Motor Insulation Class Class B
Motor Speed 2880 RPM
Motor Type Permanent Split Capacitor
Mounting Orientation Multiposition
Mounting Position All Position
Nameplate Voltage 230V AC
No. Of Inlets 2
Number Of Inlets 2
Outlet Height 1 5/8"
Outlet Shape Rectangular
Outlet Type Non Flanged
Outlet Width 4 5/8"
Overall Depth 3 5/8"
Overall Height 4 3/4"
Overall Width 14 3/4"
Phase 1
Rpm 2880
Thermal Overload Protection Yes
Thermal Protection Auto
Wheel Dia. 2 7/8"
Wheel Material Steel
Wheel Type Forward Curve
Wheel Width 3.7"
With Flange No

Shipping Info:

Ship weight (kg) 2.88
Ship height (cm)12.22
Ship length (cm)9.21
Ship width (cm)37.47
HS code8414596060
Country of OriginCN

Product Details:

    • With/Without Flange (Without Flange)

Product Variants

ProductModelOutlet ShapeDrive TypeWheel MaterialOutlet WidthAssemblyOutlet HeightHousing MaterialOverall HeightPrice
DAYTON 1TDN1 Blower 13 Cfm 115v 0.29a 3394 Rpm | AB3HBA 1TDN1RoundDirect DriveSteelNot ApplicableAssembledNot ApplicableSteel3 3/4"€118.31
DAYTON 1TDN2 Round Blower, 12 CFM, 115V, 0.08 Amp, 3340 Rpm | AB3HBB 1TDN2RoundDirect DriveSteelNot ApplicableAssembledNot ApplicableSteel3 7/8"€130.52
DAYTON 1TDN3 Blower 30 Cfm 115v 0.51a 3233 Rpm | AB3HBC 1TDN3RectangularDirect DriveSteel1 1/2"Assembled1 5/8"Steel4 5/8"€102.85
DAYTON 1TDN4 Blower 49 Cfm 115v 0.50a 3034 Rpm | AB3HBD 1TDN4RectangularDirect DriveSteel2"Assembled1 5/8"Steel4 1/2"€102.26
DAYTON 1TDN5 Blower, Ball Bearing Type, 3388 RPM, 115V AC, 0.3A, 1 Phase | AB3HBE 1TDN5RectangularDirect DriveSteel2"Assembled1 5/8"Steel4 5/8"€153.56
DAYTON 1TDN6 Blower 51 Cfm 115v 0.23a 3105 Rpm | AB3HBF 1TDN6RoundDirect DriveSteelNot ApplicableAssembledNot ApplicableSteel5 3/4"€163.32
DAYTON 1TDN7 Round OEM Blower, 50 CFM, 115V, 50/60 Hz, 0.23A, 3036 RPM | AB3HBG 1TDN7RoundDirect DriveSteelNot ApplicableAssembledNot ApplicableSteel5 3/4"€149.33
