DAYTON 23Y182 Vibrator Pneumatic Force 43.2 Lb.
Item: AB7QBJModel: 23Y182
7 In Stock
Ships within 2 days via
10.00% off
€380.22 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pneumatic Vibrator |
| Air Flow Rate | 2.6 CFM @ 87 psi |
| Application | Compacting And Detaching Of Bulk Solids Due To Perfectly Linear Vibrations. They Reach Optimum Results In Emptying Of Bins Or As Drives, Particularly Suitable For Conveying |
| Bin Weight Capacity | 432 lbs. |
| Bin Weight Capacity | 432 lb. |
| Cfm @ 60 Psi | 1.8 CFM |
| Cfm @ 60 Psi | 1.8 |
| Cfm @ 80 Psi | 2.6 |
| Cfm @ 80 Psi | 2.6 CFM |
| Compatible Muffler Grainger Part Number | 1A325 |
| Db @ 60 Psi | 82 |
| Db @ 80 Psi | 84 |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Force @ 60 Psi | Not Applicable |
| Force @ 80 Psi | Not Applicable |
| Force @ Psi | 43.2 lbf. @ 87 psi |
| Force Rating | 43.2 lb. |
| Force Rating | 43.2 lbs. |
| Housing Material | Aluminum |
| Inlet Connection Size | 1/8" |
| Inlet Connection Type | NPT |
| Inlet Port | 1/8" NPT |
| Max. Pressure | 80 psi |
| Max. Temp. | 266°F |
| Maximum Force | 43.2 lbf. |
| Maximum Inlet Pressure | 80 psi |
| Maximum Vibration Speed | 4050 VPM |
| Minimum Operating Temperature | -4°F |
| Mount Plate Included | No |
| Mount Plate Required | No |
| Mount Type | Bolt On |
| Mounting | Any Position |
| Mounting Orientation | Any Position |
| Mounting Plate | No |
| Muffler | 1A325 |
| Outlet Connection Size | 1/8" |
| Outlet Connection Type | BSPP |
| Outlet Port | 1/8" BSPP |
| Overall Height | 4.13" |
| Overall Length | 4.13" |
| Overall Width | 1.77" |
| Pneumatic Vibrator Type | Piston |
| Sound Level | 84 dBA |
| Speed @ 60 Psi | 3460 VPM |
| Speed @ 80 Psi | 4045 VPM |
| Vibration Speeds @ Psi | 3460 VPM @ 60 psi, 4045 VPM @ 80 psi |
| Vibrator Type | Piston |
Shipping Info:
| Ship weight (kg) | 0.59 |
| Ship height (cm) | 10.48 |
| Ship length (cm) | 4.45 |
| Ship width (cm) | 4.45 |
| HS code | 8479899895 |
| Country of Origin | IT |
