CRYDOM HA4875 Solid State Relay Input VAC Output VAC
Item: AF6NXAModel: HA4875Cross Ref: 1DTG9
7 In Stock
Ships within 2 days via
10.00% off
€162.10 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solid State Relay |
| Amps | 75A |
| Body Depth | 0.85" |
| Body Height | 2 1/4" |
| Body Width | 1 3/4" |
| Case Color | Black |
| Current Type | AC |
| Electrical Connection | Screw Clamp |
| Electrical Connection Type | Screw |
| Finger Safe | No |
| Frequency | 50/60 Hz |
| Heat Sink | Not Included |
| Housing Material | Aluminum |
| Input Amps | 10 mA |
| Input Power Consumption (burden) | 0.6 VA |
| Input Voltage | 90-280V AC |
| Insulation Resistance | 1000 M ohms |
| Max. Input Voltage | 280V |
| Max. Input Volts | 280 |
| Max. Output Amps | 75A |
| Max. Output Amps W/heat Sink | 75A |
| Max. Output Current Without Heat Sink | Not Recommended |
| Max. Output Voltage | 530V |
| Max. Output Volts | 530 |
| Max. Output W/heat Sink | 75A |
| Max. Output W/heat Sink (a) | 75 |
| Maximum Capacitance | 8 pF |
| Maximum Operating Temperature | 176°F |
| Maximum Output Current With Heat Sink | 75A |
| Min. Input Voltage | 90V |
| Min. Input Volts | 90 |
| Min. Output Voltage | 48 |
| Min. Output Volts | 48 |
| Minimum Operating Temperature | -40°F |
| Mounting - Relay | Surface |
| Mounting Style | Surface |
| Output Switching Mode | Zero Crossing |
| Output Voltage | 48-530V AC |
| Overall Depth | 23/25" |
| Overall Height | 0.89" |
| Phase | 1 |
| Power Factor | 0.5 |
| Relay Mounting Style | Surface |
| Relay Turns On At | Zero Crossing |
| Response Time | 30 ms |
| Series | HA Series |
| Status Indicator | Green LED Indicator |
| Switch Component Type | SCR |
| Switch Configuration | Form A |
| Switch Type | Silicon Controlled Rectifier |
| Turns On At | Zero Cross |
| Turns On At | Zero Crossing |
| Voltage/current Type | AC Output |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 7.37 |
| Ship length (cm) | 2.79 |
| Ship width (cm) | 4.83 |
| HS code | 8536490080 |
Product Variants
| Model | Input Voltage | Max. Output Amps | Min. Input Voltage | Max. Input Voltage | Body Height | Max. Output W/heat Sink (a) | Mounting Style | Switch Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| HA4812 | 90-280V AC | 12A | 90V | 280V | 2 1/4" | - | Surface | Silicon Controlled Rectifier | €111.97 | |
| HA4825 | 90-280V AC | 25A | 90V | 280V | 2 1/4" | 25A | Surface | Silicon Controlled Rectifier | €124.40 | |
| HA4850 | 90-280V AC | 50A | 90V | 280V | 2 1/4" | 50A | Surface | Silicon Controlled Rectifier | €121.11 | |
| HA4890 | 90-280V AC | 90A | 90V | 280V | - | 90A | Surface | Silicon Controlled Rectifier | €170.34 | |
| HA4825E | 18-36V AC | 25A | 18V | 36V | 2 1/4" | 25A | Surface | Silicon Controlled Rectifier | €131.14 | |
| HA4850E | 18-36V AC | 50A | 18V | 36V | 2 1/4" | 50A | Surface | Silicon Controlled Rectifier | €141.41 |
