CRYDOM CKM0630 DIN Mount Solid State Relay 60VDC 30A
Ships within 2 days via
Payment
Product Specifications:
| Item | DIN Mount Solid State Relay |
| Body Depth | 0.89" |
| Body Height | 3.16" |
| Body Width | 0.88" |
| Case Color | Black |
| Current Type | Dc |
| Electrical Connection | Screw Clamp |
| Electrical Connection Type | Screw |
| Finger Safe | Yes |
| Frequency | 50/60 Hz |
| Heat Sink | Integral |
| Input Current | 11 mA @ 32V DC, 9 mA @ 5V DC |
| Input Voltage | 4-32V DC |
| Insulation Resistance | 1000 M ohms |
| Max. Input Voltage | 32V |
| Max. Input Volts | 32 |
| Max. Output Amps | 30A |
| Max. Output Amps W/heat Sink | 30A |
| Max. Output Current Without Heat Sink | 30A |
| Max. Output Voltage | 60V |
| Max. Output Volts | 60 |
| Max. Output W/heat Sink | 30A |
| Max. Output W/heat Sink (a) | 30A |
| Max. Output W/heat Sink (a) | 30 |
| Maximum Capacitance | 8 pF |
| Maximum Operating Temperature | 176°F |
| Maximum Output Current With Heat Sink | 30A |
| Min. Input Voltage | 4V |
| Min. Input Volts | 4 |
| Min. Output Voltage | 0 |
| Min. Output Volts | 0 |
| Minimum Operating Temperature | -40°F |
| Mounting Style | Din, Flange |
| Output Voltage | 0-60V DC |
| Overall Depth | 3 24/25" |
| Overall Height | 3.9" |
| Phase | 1 |
| Relay Mounting Style | Din-Rail, Surface |
| Response Time | 1 ms |
| Series | CKM Series |
| Status Indicator | Green LED Indicator |
| Switch Component Type | Mosfet |
| Switch Configuration | Form A |
| Turns On At | Zero Crossing |
| Turns On At | Zero Cross |
| Voltage/current Type | DC Output |
Shipping Info:
| Ship weight (kg) | 0.17 |
| Ship height (cm) | 11.43 |
| Ship length (cm) | 16 |
| Ship width (cm) | 11.94 |
| HS code | 8536490080 |
| Country of Origin | MX |
Product Details:
Crydom / Sensata CKM0630 solid-state relay is ideal for efficiently switching electrical loads without the use of mechanical contacts, which minimises wear and tear. This Crydom CKM0630 relay is employed in applications, such as temperature and process control, motor drives, lighting and load switching in industrial automation and control systems.
Features:
- This solid-state relay boasts a wide range of load ratings, from 10A to 30A, making it adaptable for various electrical applications and current requirements.
- This Crydom / Sensata CKM0630 DIN mount solid-state relay features a slim and space-saving design with a width of just 22.5 mm for efficient installation in compact control panels or enclosures.
- It incorporates a low leakage MOSFET output, ensuring minimal power loss and high-efficiency switching while reducing heat generation.
- This solid state offers flexible mounting options, including DIN rail and panel mount configurations, allowing for versatile installation in control panels or directly on panels.
- It is equipped with an LED input status indicator to easily monitor the operational status of the relay, enhancing diagnostic capabilities.
Frequently Asked Questions:
Q. What is the load rating of Crydom CKM0630 solid-state relay?
A. This solid-state relay features a wide range of load ratings ranging from 10 to 30A, making it adaptable for various electrical applications and current requirements.
Q. What is the operating temperature of Crydom CKM0630 solid-state relay?
A. It has an operating temperature ranging from -40 to 80 degrees C.
Q. What wire size can this Crydom CKM0630 solid-state relay accommodate?
A. It can accommodate wires sizing up to 10 AWG.
