BRYANT 8360FR Receptacle, Single, 18-60R, 120/208V AC, 60 A, 4 Poles, Black, Screw Terminals
Item: CQ2GCBModel: 8360FRCross Ref: 49YY87
7 In Stock
Ships within 2 days via
10.00% off
€94.92 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Receptacle |
| Afci | No |
| Amps | 60A |
| Body Material | Thermoplastic |
| Connection Orientation | Straight |
| Cover Type | No Cover |
| Current Rating | 60A |
| Depth | 2 3/25" |
| Face Plate Height | 3.7" |
| Face Plate Width | 2.3" |
| Gfci | No |
| Grade | General Use |
| Grounding | Non Grounded |
| Housing Color | Black |
| Housing Material | Thermoplastic |
| Hp | 7 1/2 hp |
| Hp Rating | 7 1/2 hp |
| Includes | Mounting Hardware |
| Includes Mounting Hardware | Yes |
| Max. Wire Size | 6 AWG |
| Maximum Wire Size | 6 AWG |
| Mount Hole Center-to-center Height | 2 1/2" |
| Mount Hole Center-to-center Width | 1 4/5" |
| Mount Type | Flush |
| Mounting Hardware Included | Yes |
| Mounting Type | Flush |
| Nema Receptacle Configuration | NEMA 18-60R |
| Number Of Gangs | 1 |
| Number Of Poles | 4 |
| Number Of Wires | 4 |
| Overall Depth | 2.1" |
| Phase | Three |
| Polarized | Yes |
| Receptacle Type | Single |
| Signal & Power Protection | Standard Protection |
| Special Resistance Properties | Impact Resistant |
| Surge Protection | No |
| Voltage | 120/208V AC |
| Voltage Rating | 120/208V AC |
| Wire Connection Location | Back, Side |
| Wire Connection Type | Screw Terminals |
| Wire Connection Types | Screw Terminals |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
