BRADY DR-375-2-YL-4 622003 Precut Label Roll, 3/8 x 1/2 Inch, Polyolefin, Yellow, For 1 AWG to 8 AWG Wire Gauge
Item: AH3CPLModel: DR-375-2-YL-4Cross Ref: 31DX19 / 622003
7 In Stock
Ships within 2 days via
10.00% off
€2,668.33 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Roll |
| Adhesive | Non-Adhesive |
| Adhesive Material | Not Applicable |
| Application | Electrical Labeling, Wire And Cable Labeling |
| Color | Yellow |
| Compatible Grainger Part No. | 30DA43 |
| Compatible Manufacturer Part Number | R6600 |
| Core Diameter | 3" |
| Double-sided Printable | Yes |
| Finish | Matte |
| For Print Method | Thermal Transfer |
| For Use With | Thermal Transfer Printers |
| Height | 50 ft. |
| Label Attachment Style | Heat Shrink Sleeve |
| Label Finish | Matte |
| Label Height | 1/2" |
| Label Material | Polyolefin |
| Label Media Format | Precut Roll |
| Label Width | 3/8" |
| Labels Per Roll | 4 |
| Labels Per Row | 4 |
| Legend (remove) | Blank |
| Material Properties | Heat-Shrinkable |
| Material Series | B-7646 Series |
| Max. Lines Of Print | Varies |
| Max. Wire Size | 8/25" |
| Maximum Service Temperature | 275°F |
| Maximum Wire Diameter | 0.45" |
| Maximum Wire Gauge | 1 AWG |
| Maximum Wire Size (remove) | 0.32" |
| Media Format | Precut Roll |
| Min. Wire Size | 1/8" |
| Minimum Service Temperature | -67°F |
| Minimum Wire Diameter | 0.19" |
| Minimum Wire Gauge | 8 AWG |
| Minimum Wire Size (remove) | 1/8" |
| Preprinted Symbol (remove) | No |
| Printer Series Compatibility | Bbp72, I7100, Tht |
| Product Type | Wire Marking Sleeve |
| Recommended Ribbon | R6600 |
| Resistance Properties | Chemical Resistant, Corrosion Resistant, Diesel Resistant, Humidity Resistant,UVResistant, Weather Resistant |
| Service Temperature Range | -67°F to +275°F |
| Shrink Ratio | 3:1 |
| Temp. Range | -67°F to +275°F |
| Width | 9 1/2" |
Shipping Info:
| Ship weight (kg) | 1.25 |
| Ship height (cm) | 28.07 |
| Ship length (cm) | 13.34 |
| Ship width (cm) | 27.56 |
| Country of Origin | US |
Product Variants
| Product | Model | Color | Temp. Range | Min. Wire Size | Height | Label Width | Max. Wire Size | Max. Lines Of Print | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
HX-094-2-WT | White | -40°F to +248°F | 0.047" | 0.203" | 3/32" | 2/25" | - | €2,906.60 | |
|
HX-094-2-YL | Yellow | -40°F to +248°F | 0.047" | 0.203" | 3/32" | 2/25" | - | €2,921.30 | |
|
HX-125-2-WT | White | -40°F to +248°F | 0.062" | - | 1/8" | 0.11" | - | €2,990.60 | |
|
HX-125-2-YL | Yellow | -40°F to +248°F | 0.062" | - | 1/8" | 0.11" | - | €3,059.30 | |
 |
HX-187-2-WT | White | -40°F to +248°F | 0.094" | 0.328" | 3/16" | 0.151" | - | €3,442.18 | |
|
HX-187-2-YL | Yellow | -40°F to +248°F | 0.094" | 0.328" | 3/16" | 0.151" | - | €4,205.16 | |
 |
HX-250-2-WT | White | -40°F to +248°F | 1/8" | 0.438" | 1/4" | 0.215" | - | €1,943.56 |
