BOSTON GEAR TWF113A-300-AM1 Parallel Shaft Drive
Item: AK7CEEModel: TWF113A-300-AM1
7 In Stock
Ships within 2 days via
€4,082.30 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Drive Shaft |
| Base To Centerline Of Input Shaft | 3 1/4" |
| Base To Centerline Of Output Shaft | 3 1/4" |
| Bolt Center | 4 3/4" x 2 3/4" |
| Bore Code | B5 |
| Box Height | 4 25/32" |
| Box Length | 4" |
| Box Width | 4 3/4" |
| Center Distance | 1 3/4" |
| Family Name | TWF |
| Fan Cooled | No |
| Frame Size | 56C |
| Housing Material | Cast Iron |
| Hp @ Rpm | 1/4 hp @ 1800 RPM |
| Input (shaft Or Bore) Size | 5/8" |
| Input Configuration | C Face Quilled |
| Max. Overhung Load @ 1750 Rpm | 25 lbs.-in. |
| Max. Thrust Load @ 1150 Rpm | 25 lbs.-in. |
| Motor Application | General Purpose |
| Output (shaft Or Bore) Size | 5/8" |
| Output Configuration | Parallel, Opposite Input |
| Output Rpm @ 1750 Rpm Input | 5.8 RPM |
| Ratio | 300:1 |
| Reduction Type | Double Reduction |
| Shaft Assembly Code | AM1 |
| Torque Out @ 1750 Rpm | 280 lbs.-in. |
| Washdown Duty | No |
| Worm Position | Parallel |
Shipping Info:
| Ship weight (kg) | 4.1 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
Product Variants
| Product | Model | Frame Size | Housing Material | Price | |
|---|---|---|---|---|---|
 |
TWF113A-900-AM1 | 56C | Cast Iron | €4,082.30 |
