AUTONICS MT4Y-AA-40 36 x 72mm Multi-panel Meter Ac Amps
Get it by Tuesday, Dec 23
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Digital Panel Meter |
| Ac Magnitude Calculation | Average |
| Ac Supply Voltage | 100-240V AC |
| Ac Voltage Input | 100-240V AC |
| Ac Voltage Supply Max. | 240V AC |
| Ac Voltage Supply Min. | 100V AC |
| Accuracy | +/-0.1% Reading +/-2 Digit (23℃+/-5℃ - Full Scale), +/-0.5% Reading +/-3 Digit (-10℃ to 50℃ - Full Scale) |
| Connector Type | Screw Terminal |
| Current Display - Maximum | 5A |
| Current Display - Minimum | 0 mA |
| Depth | 3.3" |
| Digit Height - Max. | 0.559" |
| Digital Display Screen Color | Red |
| Digital Display Screen Type | LED |
| Display | Red LED Display |
| Display Digits | 4 |
| Display Span | -1999 to +9999 |
| Display Span - Max. | 9999 |
| Excitation | No |
| Excitation Voltage | No |
| Fits | 72x36mm |
| Frequency | 50/60 Hz |
| Frequency Display - Minimum | 0.1 Hz |
| Frequency Display - Maximum | 9999 Hz |
| Frequency Input | 0.1-9999 Hz |
| Function Type | Digital Panel Meter |
| Includes | Mounting Bracket |
| Includes Mounting Hardware | Included |
| Input Range | 0-5A |
| Input Signal | 0 mA-5A |
| Interface | RS-485 |
| Manufacturers Warranty Length | 3 yrs. |
| Min. Display Span | -1999 |
| Mounting | Bracket |
| Nema Enclosure Rating | NEMA 4X |
| Nema Rating | NEMA 4X Front Panel |
| Number Of Display Digits | 4 |
| Output | Relay |
| Overall Depth | 3.3" |
| Overall Height | 1.42" |
| Overall Width | 2.83" |
| Parameters Measured | AC Current |
| Relay Ac Contact Rating | 3A @ 250V AC |
| Relay Contact Form | No |
| Relay Dc Contact Rating | 3A @ 30V DC |
| Relays | 250VAC 3A,30VDC 3A |
| Series | MT4Y Series |
| Style | MT4Y Series |
| Supply Voltage | 100-240V AC |
| Terminal Connection Type | Screw Clamp |
| Transformer Type | AC Current Transformer |
| True Rms | Yes |
| Type | AC Current |
| Use With | External 5A Current Transformer |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 11.18 |
| Ship width (cm) | 8.64 |
| HS code | 9030330040 |
| Country of Origin | KR |
Product Variants
| Product | Model | Accuracy | Output | Display Span | Nema Rating | Frequency | Interface | Depth | True Rms | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
MT4Y-AV-4N | +/-0.3% Of Reading +/-3 Digit | Indicator | -1999 to +9999 | - | 50/60 Hz | RS-485 | 3.3" | Yes | €137.54 | |
|
MT4Y-AV-40 | -0.3% to +0.3% | Relay | -1999 to +9999 | NEMA 4X Front Panel | - | - | 3.3" | Yes | - | RFQ
|
