ASHCROFT G17M0215DO5000# Pressure Transmitter, 0 - 5000 PSI, 1 - 5V DC, DIN 43650 Form A Connector, 1/4 in Male NPT
Item: AE4MBCModel: G17M0215DO5000#Cross Ref: 5LRP2
7 In Stock
Ships within 2 days via
10.00% off
€245.61 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Transducer |
| Accuracy | -0.5% to +0.5% |
| Burst Pressure | 5x |
| Compatible With | Any Process Compatible With 316 Stainless Steel |
| Electrical Connection Size | DIN 43650-A |
| Electrical Connections | DIN 43650 Form A Connector |
| Enclosure Rating | IP67, NEMA 4X |
| Explosion/fire Proof | No |
| Full-scale Accuracy | -0.5% to +0.5% |
| Housing Material | 20% Glass Reinforced Nylon |
| Includes | Instructions |
| Intrinsically Safe | No |
| Ip Rating | IP67 |
| Manufacturers Warranty Length | 1 yr. |
| Max. Pressure | 7500 psi |
| Maximum Operating Temperature | 257°F |
| Maximum Pressure | 5000 psi |
| Minimum Operating Temperature | -40°F |
| Minimum Pressure | 0 psi |
| Nema Rating | NEMA 4X |
| Number Of Wires | 3 |
| Operating Temp. | -40°F to +257°F |
| Output | 1-5V DC |
| Output Voltage | 1-5V DC |
| Overpressure | 1.5 x Range |
| Power Required | 9-36V DC |
| Pressure Range | 0 psi to 5000 psi |
| Pressure Units | Psi |
| Process Connection | 1/4" Male NPT |
| Process Connection Gender | Male |
| Process Connection Size | 1/4" |
| Process Connection Size - Transmitter | 1/4" |
| Process Connection Type | NPT |
| Range | 0 psi to 5000 psi |
| Range Units | Psi |
| Response Time | 1 ms |
| Series | G2 Series |
| Storage Temperature Range | -40°F to +257°F |
| Thermal Error | -3% to +3% |
| Wetted Materials | Stainless Steel |
| Wiring Entry | Cable Gland |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 15.49 |
| Ship length (cm) | 8.13 |
| Ship width (cm) | 3.81 |
| HS code | 9026204000 |
| Country of Origin | US |
Product Variants
| Model | Number Of Wires | Power Required | Operating Temp. | Accuracy | Housing Material | Output | Wetted Materials | Pressure Range | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| T27M0242EWVAC/30#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | -15 psi to +30 psi | €348.12 | |
| T27M0242EW30#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 30 psi | €348.12 | |
| T27M0242EW60#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 60 psi | €348.12 | |
| T27M0242EW100#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 100 psi | €348.12 | |
| T27M0242EW200#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 200 psi | €348.12 | |
| T27M0242EW300#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 300 psi | €348.12 | |
| T27M0242EW500#GXCY | 2 | 9-36V DC | -40°F to +257°F | -0.25% to +0.25% | Nylon | 4-20 mA | Stainless Steel | 0 psi to 500 psi | €348.12 |
