ASHCROFT A4SAM0242F2500#G General Industrial Pressure Transducer, 0 to 500 PSI, 4 to 20mA DC, Cable, 1/4 in Male NPT
Item: CN8ZGTModel: A4SAM0242F2500#GCross Ref: 797T12
7 In Stock
Ships within 2 days via
5.00% off
€660.51 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Transducer |
| Accuracy | +/-0.25% Of Span |
| Burst Pressure | 1.5x |
| Electrical Connection | 3 Ft Shielded Cable |
| Electrical Connections | 3 Ft. Shielded Cable |
| Electrical Connections Size | 3 ft. |
| Electrical Connections Type | Shielded Cable |
| Enclosure Rating | IP65, NEMA 4X |
| Feature | Highly Configurable With A Wide Selection Of Pressure Connections, Electrical Terminations, Optional Zero, Span Access, Thin Film Technology |
| Features | Highly Configurable With A Wide Selection Of Pressure Connections And Electrical Terminations, Optional Zero And Span Access, Thin Film Technology |
| Full Scale Accuracy | ±0.25% Of Span |
| Housing Material | Stainless Steel |
| Intrinsically Safe | Yes |
| Ip Rating | IP65 |
| Length | 3.065" |
| Max. Loop Resistance | 1000 ohms |
| Max. Operating Temp. | 257°F |
| Max. Pressure | 500 psi |
| Mfr. Series | A4 Series |
| Min. Operating Temp. | -40°F |
| Nema Rating | NEMA 4X |
| No. Of Wire | 2 |
| No. Of Wires | 2 |
| Output | 4-20 mA |
| Over Pressure | 500 psi |
| Overall Height | 4.78" |
| Overall Length | 3.065" |
| Overall Width | 1.06" |
| Power Required | 12-30V DC |
| Pressure | 500 psi |
| Pressure Type | Absolute |
| Pressure Units | Psig |
| Process Connection | 1/4" Male NPT |
| Process Connection Gender | Male |
| Process Connection Size | 1/4" |
| Process Connection Type | NPT |
| Response Time | 2 ms |
| Safety Rating | Class I, Class II, Class III, Div. 1, Div. 2, Groups A, Group B, Group C, Group D, Group F, Group G , Class I, II And III Div. 1 And 2 Groups A, B, C, D, F And G |
| Storage Temp. | -40°F to +257°F |
Shipping Info:
| Ship weight (kg) | 0.1 |
| Ship height (cm) | 12.14 |
| Ship length (cm) | 7.79 |
| Ship width (cm) | 2.69 |
| Country of Origin | US |
Product Variants
| Product | Model | Max. Pressure | Process Connection Size | Process Connection Type | Pressure Units | Over Pressure | Housing Material | Burst Pressure | Pressure | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
G17M0215EW1000# | 1000 psi | 1/4" | NPT | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €294.86 | |
 |
G17M0115EW1000# | 1000 psi | 1/8" | NPT | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €287.93 | |
 |
G17MEK15EW1000# | 1000 psi | 7/16" | SAE | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €287.95 | |
 |
G17MEK15M11000# | 1000 psi | 7/16" | SAE | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €258.05 | |
 |
G17M0115M11000# | 1000 psi | 1/8" | NPT | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €270.18 | |
 |
G17M0215CD1000# | 1000 psi | 1/4" | NPT | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €272.90 | |
 |
G17M0115CD1000# | 1000 psi | 1/8" | NPT | Psi | 2x | Glass Reinforced Nylon | 5x | 0 psi to 1000 psi | €272.90 |
