ASHCROFT 20W1005PHL2DXUL2000# Pressure Gauge, General Purpose Case, 2 in Dial, 1/4 in MNPT, Right Side, ±3-2-3% Accuracy
Item: CQ8XUAModel: 20W1005PHL2DXUL2000#Cross Ref: 787NA1
7 In Stock
Ships within 2 days via
5.00% off
€26.86 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Gauge |
| Accuracy | +/-3-2-3% |
| Application | Beverage Dispensing Systems, Filter Regulators, Hydraulics, Pneumatics, Instrument, Controls, OEM Equipment, Paint Sprayers, Pumps, Compressors, Water Pumps |
| Case Color | Black |
| Case Material | ABS , Plastic |
| Display Units | psi |
| Gauge Application | General Purpose Case |
| Gauge Case Material | ABS |
| Ip Rating, Nema Rating | Not Rated |
| Lens Material | Polycarbonate |
| Lens Material Gauge | Plastic |
| Nominal Dial Size | 2" |
| Pressure | 0 psi to 2000 psi |
| Primary Display Range | 0 to 2000 |
| Primary Display Units | Psi |
| Process Connection | 1/4" MNPT |
| Process Connection Location | Right Side |
| Process Connection Size | 1/4" |
| Process Connection Type | MNPT |
| Process Temp. | -40°F to +150°F |
| Sensor Material | Bronze |
| Series | 1005 Series |
| Socket Material | Brass |
Shipping Info:
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 3.81 |
| Country of Origin | BR |
Product Variants
| Product | Model | Case Material | Lens Material | Sensor Material | Process Connection Size | Nominal Dial Size | Process Connection Location | Process Connection Type | Accuracy | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20W1005PH01B 60 PSI | ABS | Polycarbonate | Bronze | 1/8" | 2" | Center Back | NPT | +/-3-2-3% | €30.70 | |
 |
35W1005PH02LXULZG300#-8382 | Plastic | Polycarbonate | Phosphor Bronze | 1/4" | 3 1/2" | Bottom | NPT | +/-3-2-3% | €33.35 | |
 |
20W1005PH02LVAC | ABS | Polycarbonate | Bronze | 1/4" | 2" | Bottom | NPT | +/-3-2-3% | €33.46 | |
|
20W1005PH02LV/15# | ABS | Polycarbonate | Bronze | 1/4" | 2" | Bottom | NPT | +/-3-2-3% | €25.57 | |
|
20W1005PH02LV/30# | ABS | Polycarbonate | Bronze | 1/4" | 2" | Bottom | NPT | +/-3-2-3% | €25.57 | |
 |
20W1005PH02L15# | ABS | Polycarbonate | Bronze | 1/4" | 2" | Bottom | NPT | +/-3-2-3% | €25.57 | |
|
20W1005PH02L30# | ABS | Polycarbonate | Bronze | 1/4" | 2" | Bottom | NPT | +/-3-2-3% | €24.26 |
