ASHCROFT 20W1005PH 02L XRUZG 160# Pressure Gauge, General Purpose Case, 2 Inch Dial, 1/4 Inch MNPT, Bottom, ±3-2-3% Accuracy
Item: CQ8YPBModel: 20W1005PH 02L XRUZG 160#Cross Ref: 787NA9
7 In Stock
Ships within 2 days via
10.00% off
€20.54 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Gauge |
| Accuracy | +/-3-2-3% |
| Case Color | Black |
| Case Material | Plastic |
| Connection Location | Bottom |
| Display Units | psi |
| Gauge Application | General Purpose Case |
| Gauge Case Material | ABS |
| Ip Rating, Nema Rating | Not Rated |
| Lens Material | Polycarbonate |
| Lens Material - Gauge | Plastic |
| Nominal Dial Size | 2" |
| Pressure Range | 0 psi to 60 psi |
| Primary Display Range | 0 to 60 |
| Process Connection | 1/4" MNPT |
| Process Connection Location | Bottom |
| Process Temperature Range | -40°F to +150°F |
| Sensor Material | Bronze |
| Series | 1005 Series |
| Socket Material | Brass |
Shipping Info:
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 3.81 |
| Country of Origin | BR |
Product Variants
| Product | Model | Process Connection Location | Nominal Dial Size | Pressure Gauge Type | Pressure Range Type | Vibration Resistance | Lens Material | Case Color | Accuracy | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20W1005PH01B 60 PSI | Center Back | 2" | Commercial Pressure Gauge | Pressure | Liquid Filled | Polycarbonate | Black | +/-3-2-3% | €30.70 | |
 |
35W1005PH02LXULZG300#-8382 | Bottom | 3 1/2" | Fire Sprinkler System Gauge | Pressure | - | Polycarbonate | Black | +/-3-2-3% | €33.35 | |
 |
20W1005PH02LVAC | Bottom | 2" | Industrial Pressure Gauge | Vacuum | - | Polycarbonate | Black | +/-3-2-3% | €33.46 | |
|
20W1005PH02LV/15# | Bottom | 2" | Industrial Pressure Gauge | Compound | Liquid Filled | Polycarbonate | Black | +/-3-2-3% | €25.57 | |
|
20W1005PH02LV/30# | Bottom | 2" | Industrial Pressure Gauge | Compound | Liquid Filled | Polycarbonate | Black | +/-3-2-3% | €25.57 | |
 |
20W1005PH02L15# | Bottom | 2" | Industrial Pressure Gauge | Pressure | Liquid Filled | Polycarbonate | Black | +/-3-2-3% | €25.57 | |
|
20W1005PH02L30# | Bottom | 2" | Industrial Pressure Gauge | Pressure | Liquid Filled | Polycarbonate | Black | +/-3-2-3% | €24.26 |
