ARCH CUTTING TOOLS MH40 MWLNL4-CFT Boring Bar
Get it by Tuesday, Sep 1
€517.28 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Boring Bar |
| Bar Dia. | 2.500" |
| Bar Dia. | 2 1/2" |
| Center To Cutting Tip | 1 1/2" |
| Compatible Hardware | Clamp CL-20, Clamp Screw XNS-47, Lock Pin NL-46, Shim IWSN-433 |
| Connection Size | Mh40 (2 1/2" Head Diameter) |
| Coolant Fed | Coolant Through |
| Cutting Angle | -5° |
| Cutting Application | Boring |
| Cutting Direction | Left |
| Cutting Edge Angle | -5° |
| Hardware Required | Clamp Cl-20, Clamp Screw Xns-47, Lock Pin Nl-46, Shim Iwsn-433 |
| Inscribed Circle | 1/2" |
| Insert Clearance Angle | 0° |
| Insert Holding Type | Clamp And Lock Pin |
| Insert Inscribed Circle | 1/2" |
| Insert Shape | Trigon |
| Insert Size | 432 |
| Insert Style | WNMG |
| Insert Thickness | 0.187" |
| Lead Angle | -5° |
| Min. Bore Dia. | 2.98" |
| Mounting Style | Clamp And Lock Pin |
| Overall Length | 1 5/8" |
| Rake | Negative |
| Shank Material | Steel |
| Side Cutting Edge Angle | -5° |
| Style | Chatter Free |
| Toolholder Style | Mwln |
| Type | Turning |
Shipping Info:
| Ship weight (kg) | 0.72 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 6.68 |
| Ship width (cm) | 11.43 |
| Country of Origin | US |
Product Variants
| Product | Model | Min. Bore Dia. | Bar Dia. | Mounting Style | Insert Size | Cutting Direction | Inscribed Circle | Rake | Lead Angle | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MH16 LSEL3-CFT | 1 1/5" | 1" | Screw Lock | - | Left | 3/8" | Neutral | 0° | €459.53 | |
|
MH16 LSER3-CFT | 1 1/5" | 1" | Screw Lock | - | Right | 3/8" | Neutral | - | €421.84 | |
 |
MH16 MCLNL4-CFT | 1.2" | 1" | Clamp And Lock Pin | 432 | Left | 1/2" | Negative | -5° | €438.14 | |
|
MH16 MCLNR4-CFT | 1.2" | 1" | Clamp And Lock Pin | 432 | Right | 1/2" | Negative | -5° | €399.56 | |
 |
MH16 MDUNL3-CFT | 1.3" | 1" | Clamp And Lock Pin | 332 | Left | 3/8" | Negative | -3° | €438.14 | |
|
MH16 MDUNR3-CFT | 1.3" | 1" | Clamp And Lock Pin | 332 | Right | 3/8" | Negative | -3° | €399.56 | |
 |
MH16 MTUNR3-CFT | 1.2" | 1" | Clamp And Lock Pin | 332 | Right | 3/8" | Negative | -3° | €399.56 |
