APPROVED VENDOR 24W703 Hydraulic Reservoir 10 Gallon Capacity
Get it by Tuesday, Dec 23
10.00% off
€520.60 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Hydraulic Reservoir |
| Application | For Mobile And Industrial Hydraulic Systems |
| Baffle Plate Included | Yes |
| Cover Material | Steel |
| Drain Plug Connection Size | 3/4" |
| Drain Plug Connection Type | NPT |
| Drain Plug Size | 3/4" |
| Drain Plug Type | NPT |
| Finish | Paint |
| Gasket | Buna N |
| Gasket Material | Buna-N |
| Includes | (2) 6" Cleanout Covers And Drain, Filler Breather, Mounting Feet, Oil Sight Gauge With Thermometer, Suction/Return Ports |
| Length | 22 1/4" |
| Material | Steel |
| Mounting Orientation - Power Units | Horizontal |
| Mounting Position | Horizontal |
| Nominal Capacity | 10 gal. |
| Overall Height | 12 1/4" |
| Overall Length | 22.25" |
| Overall Width | 14" |
| Removable Cover Included | Yes |
| Return Port | 3/4 NPT |
| Return Port Size | 3/4" |
| Return Port Thread Size | 3/4" |
| Return Port Thread Type | NPT |
| Return Port Type | NPT |
| Suction Port Thread Size | 1 1/2" |
| Suction Port Thread Size Type | NPT |
| Tank Material | 11 ga. Steel |
| Usable Capacity | 1640 cu. in. |
| Width | 14" |
Shipping Info:
| Ship weight (kg) | 28.51 |
| Ship height (cm) | 34.29 |
| Ship length (cm) | 61.47 |
| Ship width (cm) | 42.93 |
| HS code | 7310290050 |
| Country of Origin | IN |
Product Details:
- Breather Cap (Yes)
- Removable Cover (No)
- Suction Port Size (In.) (1-1/2 NPT)
