APPROVED VENDOR 1NWC6 V-groove Swivel Caster 1000 Lb. 2 W
Get it by Tuesday, Dec 23
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€86.61 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | V-Groove Swivel Caster |
| Bearing Type | Double Ball |
| Caster Brake Type | No Brake Included |
| Caster Frame Material | Steel |
| Caster Load Rating Range | 1000 lbs. to 2999 lbs. |
| Caster Product Group | Swivel Caster |
| Caster Sub-type | Swivel |
| Core Color | Black |
| Core Material | Cast Iron |
| Frame Finish | Zinc Plated |
| Frame Material | Steel |
| Hole Pattern | B |
| Includes Thread Guards | No |
| Inside Bolt Hole Spacing | 3" x 3" |
| Load Rating | 1000 lbs. |
| Material | Cast Iron |
| Mounting Bolt Dia. | 3/8" |
| Mounting Height | 7 1/2" |
| Mounting Plate Bolt Hole Pattern | B |
| Mounting Plate Size | 4" x 4 1/2" |
| Mounting Plate Size & Bolt Hole Pattern | 4" X 4 1/2" ( B ) |
| Non-marking | Yes |
| Number Of Mounting Holes | 4 |
| Number Of Wheels | 1 |
| Outside Bolt Hole Spacing | 3" x 3 5/8" |
| Overall Height | 7 1/2" |
| Plate Thickness | 1/4" |
| Plate Type | A |
| Raceway | Double Ball Hardened |
| Recommended Track Size | 2 5/8" x 3 5/8" |
| Replacement Wheel | 1NWB9 |
| Swivel Construction | Kingpin |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Double Ball |
| Tread Shape | V Groove |
| Type | Swivel |
| Wheel Bearing Type | Roller |
| Wheel Color | Black |
| Wheel Core Material | Cast Iron |
| Wheel Dia. | 6" |
| Wheel Material | Cast Iron |
| Wheel Width | 2" |
| Wheel/tread Hardness Rating | Extra Hard |
| Wheel/tread Material | Iron |
Shipping Info:
| Ship weight (kg) | 4.57 |
| Ship height (cm) | 22.86 |
| Ship length (cm) | 35.56 |
| Ship width (cm) | 35.56 |
| HS code | 8716903000 |
| Country of Origin | CN |
Product Variants
| Product | Model | Wheel Dia. | Wheel Width | Load Rating | Mounting Height | Mounting Bolt Dia. | Caster Load Rating Range | Inside Bolt Hole Spacing | Outside Bolt Hole Spacing | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1NWB2 | 4" | 1 1/2" | 800 lbs. | 5 5/8" | 3/8" | 300 lbs. to 999 lbs. | 3" x 3" | 2 5/8" x 3 5/8" | €59.42 | |
|
1NWC2 | 4" | 1 1/2" | 800 lbs. | 5 5/8" | 3/8" | 300 lbs. to 999 lbs. | 3" x 3" | 2 5/8" x 3 5/8" | €85.67 | |
 |
1NWD5 | 4" | 2" | 800 lbs. | 5 5/8" | 1/2" | 300 lbs. to 999 lbs. | 2 7/16" x 4 15/16" | 3 3/8" x 5 1/4" | €62.01 |
