APPLETON ELECTRIC NCP-20232 Plug, 6-20P, 20 A, 250V AC, 3 Poles, Non-Metallic
Item: AA3YAQModel: NCP-20232Cross Ref: 11Y426
7 In Stock
Ships within 2 days via
10.00% off
€381.85 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Plug |
| Amps | 20A |
| Blade Material | Brass |
| Body Length | 2.78" |
| Connection Orientation | Straight |
| Current Rating | 20A |
| Face Dia. | 1 3/4" |
| For Environment | Hazardous Location |
| For Maximum Cable Dia. | 0.639" |
| For Minimum Cable Diameter | 0.538" |
| Grounding | Grounded |
| Hazardous Location Specification | Class I, Div 1 And 2, Group B, C, D, Class Ii, Div 1 And 2, Group F, Class Iii, Div 1 And 2 |
| Horsepower Rating | 2 hp |
| Housing Color | Black |
| Insulation Material | Thermoplastic |
| Ip Rating | Not Rated |
| Nema Plug Configuration | 6-20P |
| Nema Rating | 3, 3R, 7BCD, 9FG |
| Nema Type | NEMA 6-20P |
| Nema Type | 6-20P |
| No. Of Blades | 3 |
| Number Of Poles | 3 |
| Number Of Wires | 2 |
| Outside Dia. | 1 3/4" |
| Overall Length | 2.78" |
| Phase | Single |
| Polarized | No |
| Product Datasheet | appleton-electric-ncp-20232.pdf |
| Resistance Properties | Corrosion Resistant |
| Shrouded | No |
| Ul 94 Flammability Rating | Not Rated |
| Voltage | 250V |
| Voltage Rating | 250V AC |
| Wire Connection Type | Screw Terminals |
| Wiring Style | Standard |
Shipping Info:
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 9.91 |
| Ship length (cm) | 12.45 |
| Ship width (cm) | 10.67 |
| HS code | 8536698000 |
| Country of Origin | MX |
