ANVIL FIG 82 Short Spring Hanger, Corrosion Resistant

Features:

• Anvil FIG 82 short spring hanger features a pre-compressible spring for reducing the length of the hanger, thus minimising space requirement.
• The spring hanger also reduces the height of the overall installed assembly.
• It also prevents the spring supporting force from increasing / exceeding the normal safe limit.
• This Anvil spring hanger is pre-calibrated for accurate loading conditions.
• It features a load indicator for displaying the load, thus simplifying the reading of the scale plate.
• This Anvil pipe hanger has a steel spring and casing for withstanding heavy loads for extended periods.
• It can handle temperatures up to 200 degrees F.

Standards and Approvals:

• WW-H-171E
• ANSI/MSS SP-69 and MSS SP-58
• ASME

Frequently Asked Questions:

Q. How to choose a spring hanger?

A. Firstly, the user should determine the pipe movement margin and load rating. The spring should be selected which falls under the working travel range of the piping system.

Q. How do variable spring hangers work?

A. They are used in conditions where the supporting components are capable of withstanding load variations up to 25 percent. The compression spring coil is pre-compressed to some initial load settings in these spring hangers.

Q. How do I determine the appropriate size of a short spring hanger for my project?

A. The size is determined based on the pipe diameter and the load requirements.
