AIR HANDLER 5M344 Pocket Air Filter, 24 x 20 x 15 Inch Nominal Filter Size, Orange, Synthetic, 10 Pockets, 190 Deg. Max Temp
Get it by Thursday, Jul 2
5.00% off
€71.66 /unit
This product can only be shipped in multiples of 4Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Pocket Air Filter |
| Actual Depth | 15" |
| Actual Filter Size | 23 3/8" x 11 3/8" x 15 |
| Actual Height | 23 3/8" |
| Actual Width | 19 3/8" |
| Air Filter Header Type | Single Header |
| Air Flow @ 500 Fpm | 1667 CFM |
| Airflow @ 300 Fpm | 1000 CFM |
| Airflow Rate | 500 FPM |
| Capacity Cfm | 1250 CFM |
| Filter Efficiency | 65% |
| Filter Efficiency (air Filters) | 60% to 65% |
| Filters Out | Auto Emission Particulates, Coal Dust, Humidifier Dust, Lead Dust, MERV 9-12 Legionella, Milled Flour, Nebulizer Droplets |
| Final Resistance | 1 in. wc |
| Frame Finish | Galvanized |
| Frame Material | Steel |
| Frame Or Header Material | Galvanized Steel |
| Frame Size | 0.812" |
| Initial Resistance | 0.37 in. wc |
| Initial Resistance @ 300 Fpm | 0.33 in. wc |
| Initial Resistance @ 500 Fpm | 0.55 in. wc |
| Material | Synthetic |
| Material Thickness | 24 ga. |
| Max. Temp. | 190°F |
| Max. Velocity | 500 FPM |
| Media Area | 40 sq. ft. |
| Media Color | Orange |
| Media Material | Synthetic |
| No. Of Pockets | 10 |
| Nominal Depth | 15" |
| Nominal Filter Size | 24" x 20" x 15" |
| Nominal Height | 24" |
| Nominal Width | 20" |
| Performance Rating | MERV 11 |
| Recommended Final Resistance | 1 in. wc |
| Removes Particles Down To | 1 µm to 3 µm |
| Standards | Ul 900 |
| Style-air Filters | Bag |
Shipping Info:
| Ship weight (kg) | 9.05 |
| Ship height (cm) | 60.96 |
| Ship length (cm) | 53.09 |
| Ship width (cm) | 26.42 |
| HS code | 8421398090 |
| Country of Origin | US |
Product Variants
| Product | Model | Media Color | Max. Temp. | Nominal Filter Size | Performance Rating | Media Material | Nominal Height | Nominal Width | Nominal Depth | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
2DVT9 | Orange | 150°F | 24" x 24" x 15" | MERV 11 | Fiberglass | 24" | 24" | 15" | - | RFQ
|
 |
2GGA1 | Orange | 150°F | 24" x 20" x 22" | MERV 11 | Fiberglass | 24" | 20" | - | €78.72 | |
 |
2GGA5 | Green | 150°F | 20" x 20" x 22" | MERV 11 | Fiberglass | 20" | 20" | - | €65.12 | |
 |
2GGC5 | Orange | 150°F | - | - | - | 20" | 24" | - | €161.24 | |
|
2GGU4 | Orange | 150°F | 20" x 20" x 22" | MERV 11 | Fiberglass | 20" | 20" | 22" | €65.29 | |
|
2GHF2 | Orange | 150°F | 24" x 12" x 29" | MERV 11 | Fiberglass | 24" | 12" | 29" | €67.23 | |
|
2GHG1 | Orange | 150°F | 24" x 12" x 15" | MERV 11 | Fiberglass | 24" | 12" | 15" | €71.77 |
