AIGNEP 59130-8 Push to Connect Fitting, Brass, Push-to-Connect x Push-to-Connect, For 8 mm x 8 mm Tube OD
Item: CL7UVNModel: 59130-8Cross Ref: 787W23
7 In Stock
Ships within 2 days via
10.00% off
€18.01 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Application | Air, Food Processing, Potable Water, Steam, Vacuum |
| Color | Silver |
| Compatible Tube Material | FEP, PA11, PA12, PA6, Polyethylene, Polyurethane, PTFE |
| Fitting Material | Brass |
| Fitting Side A Connection Type | Push-To-Connect |
| Fitting Side A Tube Outer Dia. | 8 mm |
| Fitting Side B Connection Type | Push-To-Connect |
| Fitting Side B Tube Outer Diameter | 8 mm |
| Fitting Thread Size | 1/4" |
| Includes Pre-applied Thread Sealant | No |
| Maximum Operating Pressure | 290 psi |
| Maximum Operating Temperature | 374°F |
| Minimum Operating Temperature | 5°F |
| Overall Length | 15/16" |
| Release Ring Material | PPSU |
| Release Type | Collet |
| Resistance Properties | Impact Resistant, Vibration Resistant |
| Specific Fitting Angle | 90° |
| Specific Fitting Shape | Elbow |
| System Of Measurement | Imperial/Metric |
| Thread Sealant Type | FKM |
Shipping Info:
| Ship weight (kg) | 0.45 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.38 |
| Ship width (cm) | 2.54 |
| Country of Origin | IT |
