ABLOY AUR88182FL X 626 X YMS Mortise Lockset Lever Classroom Intruder
Item: AE6XJGModel: AUR88182FL X 626 X YMSCross Ref: 5VTC2
7 In Stock
Ships within 2 days via
10.00% off
€941.13 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Mortise Lockset |
| Ada Compliant | Yes |
| Ansi Grade | Grade 1 |
| Ansi Lockset Function | Classroom |
| Backset | 2 3/4" |
| Bolt Type | Latch Bolt |
| Cylinder Core Type | Large Format Interchangeable Core Cylinder |
| Door Thickness - Maximum | 3 1/4" |
| Door Thickness - Minimum | 1 3/4" |
| Finish | Satin Chrome Plated |
| Fire Rating | 3 hrs. |
| Function | Classroom Intruder |
| General Lockset Function | Classroom Lever Locksets |
| Hand Orientation | Non Handed |
| Handle Material | Brass |
| Includes Core | Yes |
| Inside Locking Access | Not Lockable |
| Key Type | Keyed Different |
| Keying | Keyed Different |
| Keyway Type | Yale Para |
| Ligature Resistance | Not Ligature Resistant |
| Location Type | Commercial |
| Lock Assembly Type | Mortise |
| Lockset Handle Type | Lever |
| Lockset Style | Augusta |
| Lockset Type | Mechanical |
| Material | Steel |
| Mounting Style | Thru Bolt |
| Number Of Keys | 2 |
| Number Of Pins | 6 |
| Outside Locking Access | Keyway |
| Performance Duty Rating | 1 |
| Pins | 6 |
| Properties | Vandal Resistant |
| Required Door Thickness | 1 3/4" |
| Strike Length | 4 7/8" |
| Strike Plate Height | 4 7/8" |
| Strike Plate Width | 1 1/4" |
| Strike Type | Curved Lip |
| Strike Width | 1 1/4" |
| Style | Right Angle |
| Trim Plate Shape | Rectangular |
| Trim Style | Rose |
| Visual Indicator Message | No Message |
Shipping Info:
| Ship weight (kg) | 3.02 |
| Ship height (cm) | 11.94 |
| Ship length (cm) | 22.61 |
| Ship width (cm) | 17.27 |
| HS code | 8301406030 |
| Country of Origin | US |
Product Variants
| Product | Model | Finish | Style | Key Type | Handle Material | Keyway Type | Backset | Fire Rating | Required Door Thickness | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
AUCN8807FL x 626 | Satin Chrome Plated | Right Angle | Keyed Different | - | Para | 2 3/4" | 3 hrs. | - | €900.71 | |
 |
AUCN8805FLX626 | Satin Chrome Plated | - | Keyed Different | - | Para | 2 3/4" | 3 hrs. | - | €892.83 | |
 |
AUCN88182FL x 626 | Dull Chrome | - | Keyed Different | - | Para | - | 3 hrs. | - | €990.21 | |
 |
8831-CO-CN-626-SA KEYWAY-6PIN-0-BITTED | Satin Chrome | Knob | Keyed Different | - | Yale SA | 2 3/4" | 3 hrs. | 1 3/4" | €1,186.10 | |
 |
AUCN8801FL x 626 | Satin Chrome Plated | Right Angle | Not Keyed | Zinc | - | 2 3/4" | 3 hrs. | - | €810.64 | |
 |
AUCN8802FL x 626 | Satin Chrome Plated | - | Not Keyed | Zinc | - | 2 3/4" | 3 hrs. | - | €826.26 | |
 |
AUCN8867FL x 626 | Satin Chrome Plated | Right Angle | Keyed Different | Zinc | Yale Para | 2 3/4" | 3 hrs. | 1 3/4" | €930.75 |
