3M 7010320786 80611465628 / 58916 / MNHU18-250DFIX Female Disconnect, Red, Full, 221 Degrees F, 0.032 Inch x 0.250 Inch Tab Size
Item: AC9XCLModel: 7010320786Cross Ref: 3LB47 / 80611465628 / 58916 / MNHU18-250DFIX
7 In Stock
Ships within 2 days via
10.00% off
€99.00 /pkg. of 25
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Female Disconnect |
| Barrel Id | 0.08" |
| Barrel Inside Dia. | 2/25" |
| Color Code | Red |
| Connection Material | Tin Plated Brass |
| Connection Type | Crimp |
| Connection Width | 1/4" |
| Diameter (d) | 0.23" |
| Disconnect Type | Female |
| Fastener Orientation | Female |
| Insulation | Full |
| Insulation Color | Red |
| Insulation Type | Heat Shrink |
| Male Tab Width (w') | 1/4" |
| Max. Temp. | 221°F |
| Max. Voltage | 600V |
| Maximum Conductor Size | 18 AWG |
| Min. Conductor Size | 22 AWG |
| Overall Dia. | 0.23" |
| Overall Length | 1 1/5" |
| Pad Width | 1/4" |
| Seam | Butted |
| Tab Width | 0.187" |
| Terminal Style | Fully Insulated |
| Terminal Type | Female Disconnect |
| Wire Range | 22 AWG to 18 AWG |
| Wire Size | 22 AWG to 18 AWG |
Shipping Info:
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 3.05 |
| Ship width (cm) | 5.08 |
| HS code | 8536904000 |
| Country of Origin | US |
Product Variants
| Product | Model | Wire Size | Insulation Color | Insulation Type | Color Code | Barrel Inside Dia. | Wire Range | Insulation | Connection Type | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
7000132444 | 12 AWG to 10 AWG | Yellow | Nylon | Yellow | - | 12 AWG to 10 AWG | Full | Crimp | 250 | €702.93 | |
 |
7100164285 | 22 AWG to 18 AWG | Red | Nylon | Red | 2/25" | 22 AWG to 18 AWG | Full | Crimp | 250 | €590.27 | |
 |
7000132451 | 16 AWG to 14 AWG | Blue | Nylon | Blue | 2/25" | 16 AWG to 14 AWG | Full | Crimp | 250 | €575.65 | |
|
7000133382 | 12 AWG to 10 AWG | Yellow | Heat Shrink | Yellow | 0.165" | 12 AWG to 10 AWG | Full | Crimp | 25 | €162.00 | |
 |
7000133391 | 16 AWG to 14 AWG | Blue | Heat Shrink | Blue | 2/25" | - | Full | Crimp | 25 | €97.95 |
