ACCURIDE 2109 Series Light Duty Slides With Lever Disconnect

Item: AD8KLW
Model: C 2109-12D
Cross Ref: 4KRN9
Check Availability
In Stock

Get it by Dec 30, Tuesday

Closed Length
€46.76
10% off
€42.08 /unit (ex. VAT)
Add To Cart
Request Quote

Payment

Delivery

  • Specifications
  • Shipping Information

Specifications

Item Drawer Slide
Closed Length 11 13/16"
Closure Type Non Self Closing
Color Silver
Cycle Life 50000
Detent Type Hold In/Hold Out
Disconnect Method Lever
Duty Rating Light Duty (<140 lbs.)
Extended Length 19 7/8"
Extension Type 3/4 Extension
Finish Zinc Plated
For Use With Drawers
Glide Mechanism Ball Bearing
Hardware Not Included
Height 1 13/16"
Includes Hardware Hardware Included
Load Capacity 75 lbs.
Material Steel
Mounting Type Bracket
Overall Height 1 3/8"
Overall Width 1/2"
Product Type Drawer Slide
Screw Head Type Pan
Screw Size #8
Screw Type Pan Head
Side Mount Load Cap. Per Pair 75 lbs.
Side Space 1/2"
Side Space - Maximum 1/2"
Travel Length 8 3/32"
Width 1/2"
Standards AWI, BHMA, ROHS

Shipping Information

Height (cm) 6.35
Length (cm) 30.48
Width (cm) 7.62
HS Code 8302423015
Country Of Origin MX
Weight (kg) 0.86
