KHK GEARS Worm Gears

Filter

Style	Model	Module Pitch	Outside Dia.	Pressure Angle	Face Width	Bore Dia.	Pitch Dia.	Hub Dia.	Hub Projection	Price
A	DG0.5-50R1	0.5	26 mm	20°	5 mm	5 mm	25.03 mm	20 mm	7 mm	€27.75
B	SW0.5-R1	0.5	12 mm	-	10 mm	5 mm	11 mm	-	-	€28.27
A	DG0.5-30R1	0.5	16 mm	20°	5 mm	4 mm	-	12 mm	7 mm	€21.49
C	BG0.5-30R1	0.5	16 mm	20°	5 mm	4 mm	15.02 mm	12 mm	7 mm	€49.84
D	SUW0.5-R1	0.5	12 mm	20°	10 mm	5 mm	11 mm	-	-	€59.80
E	KWG0.5-R2	0.5	10 mm	20°	12 mm	-	9 mm	-	-	€181.21
B	SW0.5-R2	0.5	12 mm	20°	10 mm	5 mm	11 mm	-	-	€28.27
E	KWG0.5-R1	0.5	10 mm	20°	12 mm	-	9 mm	-	-	€168.14
C	BG0.5-60R1	0.5	31 mm	20°	5 mm	5 mm	30.03 mm	25 mm	7 mm	€81.39
D	SUW0.5-R2	0.5	12 mm	20°	10 mm	5 mm	11 mm	-	-	€59.80
A	DG0.5-60R1	0.5	31 mm	20°	5 mm	5 mm	30.03 mm	25 mm	7 mm	€31.37
F	AG0.5-60R1	0.5	31 mm	20°	5 mm	5 mm	30 mm	25 mm	7 mm	€101.44
F	AG0.5-40R1	0.5	21 mm	20°	5 mm	5 mm	20 mm	15 mm	7 mm	€79.66
A	DG0.5-40R1	0.5	21 mm	20°	5 mm	5 mm	20.02 mm	15 mm	7 mm	€24.48
C	BG0.5-40R1	0.5	21 mm	20°	5 mm	5 mm	20.02 mm	15 mm	7 mm	€62.73
C	BG0.5-50R1	0.5	26 mm	20°	5 mm	5 mm	25.03 mm	20 mm	7 mm	€71.62
F	AG0.5-50R1	0.5	26 mm	20°	5 mm	5 mm	25 mm	20 mm	7 mm	€82.20
F	AG0.5-30R1	0.5	16 mm	20°	5 mm	4 mm	15 mm	12 mm	7 mm	€60.49
F	AG0.5-30R2	0.5	16 mm	20°	5 mm	4 mm	15 mm	12 mm	7 mm	€60.49
F	AG0.5-20R1	0.5	11 mm	20°	5 mm	4 mm	10 mm	9 mm	7 mm	€58.00
A	DG0.5-20R2	0.5	11 mm	20°	5 mm	4 mm	10.04 mm	9 mm	7 mm	€20.01
F	AG0.5-20R2	0.5	11 mm	20°	5 mm	4 mm	10 mm	9 mm	7 mm	€58.00
C	BG0.5-20R2	0.5	11 mm	20°	-	4 mm	10.04 mm	9 mm	7 mm	€39.70
A	DG0.5-20R1	0.5	11 mm	20°	5 mm	4 mm	-	9 mm	7 mm	€20.01
C	BG0.5-20R1	0.5	11 mm	20°	5 mm	4 mm	10.01 mm	9 mm	7 mm	€39.70
A	DG0.5-30R2	0.5	16 mm	20°	5 mm	-	15.06 mm	12 mm	7 mm	€21.49
C	BG0.5-30R2	0.5	16 mm	20°	5 mm	4 mm	15.06 mm	12 mm	7 mm	€49.84
F	AG0.8-30R2	0.8	25.6 mm	20°	8 mm	5 mm	24 mm	18 mm	8 mm	€82.95
A	DG0.8-20R1	0.8	17.6 mm	20°	9 mm	5 mm	16.03 mm	12 mm	9 mm	€22.28
C	BG0.8-20R2	0.8	17.6 mm	20°	9 mm	5 mm	-	12 mm	9 mm	€50.03
F	AG0.8-50R1	0.8	41.6 mm	-	8 mm	8 mm	40 mm	25 mm	8 mm	€110.77
A	DG0.8-20R2	0.8	17.6 mm	20°	9 mm	5 mm	16.11 mm	12 mm	9 mm	€22.28
F	AG0.8-20R2	0.8	17.6 mm	20°	8 mm	5 mm	16 mm	12 mm	8 mm	€69.20
C	BG0.8-30R1	0.8	25.6 mm	20°	-	5 mm	24.04 mm	18 mm	9 mm	€70.32
A	DG0.8-50R1	0.8	41.6 mm	20°	9 mm	8 mm	40.07 mm	25 mm	9 mm	€40.39
D	SUW0.8-R2	0.8	15.6 mm	20°	18 mm	6 mm	14 mm	-	-	€84.32
A	DG0.8-60R1	0.8	49.6 mm	20°	9 mm	8 mm	48.08 mm	25 mm	9 mm	€48.72
F	AG0.8-60R1	0.8	49.6 mm	20°	8 mm	8 mm	48 mm	25 mm	8 mm	€136.96
A	DG0.8-30R2	0.8	25.6 mm	20°	9 mm	5 mm	24.16 mm	18 mm	9 mm	€27.48
C	BG0.8-60R1	0.8	49.6 mm	20°	9 mm	8 mm	48.08 mm	25 mm	9 mm	€122.40
F	AG0.8-20R1	0.8	17.6 mm	20°	8 mm	5 mm	16 mm	12 mm	8 mm	€70.70
C	BG0.8-50R1	0.8	41.6 mm	20°	9 mm	8 mm	40.06 mm	25 mm	9 mm	€106.46
E	KWG0.8-R1	0.8	13.6 mm	20°	-	-	12 mm	-	-	€175.79
D	SUW0.8-R1	0.8	15.6 mm	20°	18 mm	6 mm	14 mm	-	-	€84.32
B	SW0.8-R2	0.8	15.6 mm	20°	18 mm	6 mm	14 mm	-	-	€35.97
E	KWG0.8-R2	0.8	13.6 mm	20°	20 mm	-	-	-	-	€192.59
C	BG0.8-30R2	0.8	25.6 mm	20°	9 mm	5 mm	24.16 mm	18 mm	-	€70.70
C	BG0.8-20R1	0.8	17.6 mm	20°	9 mm	5 mm	16.03 mm	12 mm	9 mm	€50.03
B	SW0.8-R1	0.8	15.6 mm	20°	18 mm	6 mm	14 mm	-	-	€35.97
F	AG0.8-40R1	0.8	33.6 mm	20°	8 mm	6 mm	32 mm	20 mm	-	€96.63
A	DG0.8-30R1	0.8	25.6 mm	20°	9 mm	5 mm	24.04 mm	18 mm	9 mm	€27.48
F	AG0.8-30R1	0.8	25.6 mm	20°	8 mm	5 mm	24 mm	-	-	€82.95
C	BG0.8-40R1	0.8	33.6 mm	20°	9 mm	-	32.05 mm	20 mm	9 mm	€81.39
A	DG0.8-40R1	0.8	33.6 mm	20°	9 mm	6 mm	32.05 mm	20 mm	9 mm	€33.97
D	SUW1-R1	1	18 mm	20°	20 mm	6 mm	16 mm	-	-	€101.18
G	CG1-80R1	1	83 mm	20°	10 mm	10 mm	80.16 mm	35 mm	10 mm	€86.32
F	AG1-20R1	1	23 mm	20°	10 mm	6 mm	20 mm	16 mm	10 mm	€81.34
E	KWG1-R1	1	18 mm	20°	30 mm	-	16 mm	-	-	€199.13
H	SWG1-R1	1	18 mm	20°	20 mm	8 mm	16 mm	-	-	€166.46
I	PG1-30R1	1	33 mm	20°	10 mm	6 mm	30.06 mm	20 mm	10 mm	€50.78
C	BG1-30R1	1	33 mm	20°	10 mm	6 mm	30.07 mm	20 mm	10 mm	€80.77
