EATON Harmonic Mitigating Transformers


Eaton harmonic mitigating transformers are designed to reduce the level of harmonic distortion in electrical systems.

Filter
EATON X29M28T3016CUNONA
EATON X48M28T2216NONB
StyleModelSecondary VoltageHeightPrimary VoltageCoil MaterialTemp.VoltagePhase ShiftVaPrice
A
X29M28T3016CUNON		120/208V36 22/25"208VCopper150°C208/120V0 AA30 kVA€14,094.95
A
X48M28T7516CUNON		120/208V-480VCopper150°C480-208/120V AC0 AA75 kVA€20,160.58
A
X48M28T4516CUNONLS45		120/208V36 22/25"480VCopper150°C480-208/120V AC0 AA45 kVA€16,233.15
A
X48M28T4516NON		120/208V36 22/25"480VAluminum150°C480-208/120V AC0 AA45 kVA€10,022.74
A
X48M28T3316CUTHR		120/208V1.1"480VCopper150°C480-208/120V AC-30 AA300 kVA€69,796.19
A
X48M28T1216NON		120/208V51"480VAluminum150°C480-208/120V AC0 AA112.5 kVA€20,189.53
A
X48M28T3016CUNON		120/208V36 22/25"480VCopper150°C480-208/120V AC0 AA30 kVA€11,277.45
A
X48M28T4516CUNON		120/208V36 22/25"480VCopper150°C480-208/120V AC0 AA45 kVA€13,527.00
A
X48M28F1216CUTHR		120/208V51"480VCopper115°C480-208/120V AC-30 AA112.5 kVA€34,207.27
A
X48M28T2216CUTHR		120/208V1.1"-Copper150°C480-208/120V AC-30 AA225 kVA€47,770.65
A
X48M28B4516CUNON		120/208V43"480VCopper80°C480-208/120V AC0 AA45 kVA€20,290.51
A
X48M28F1216CUPOS		120/208V1.1"480VCopper115°C480-208/120V AC15 AA112.5 kVA€33,700.19
A
X48M28T1216CUNON		120/208V51"480VCopper150°C480-208/120V AC0 AA112.5 kVA€25,923.29
A
X48M28T7516CUTHR		120/208V43"480VCopper150°C480-208/120V AC-30 AA75 kVA€20,160.58
A
X48M28F1216CUNEG		120/208V1.1"480VCopper115°C480-208/120V AC-15 AA112.5 kVA€33,700.19
A
X48M28T7516NON		120/208V43"480VAluminum150°C480-208/120V AC0 AA75 kVA€13,425.29
A
X48M28T4916CUNON		208Y/120V51"480VCopper150°C480-208/120V AC0 AA150 kVA€34,990.52
A
X48M28T4916NON		208Y/120V51"480VAluminum150°C480-208/120V AC0 AA150 kVA€27,395.52
B
X48M28T2216NON		208Y/120V60"480VAluminum150°C480-208/120V AC0 AA225 kVA€41,811.18
A
X48M28T3016CUTHR		208Y/120V36 22/25"-Copper150°C480-208/120V AC-30 AA30 kVA€11,277.45
A
X48M28T3016NON		208Y/120V36 22/25"480VAluminum150°C480-208/120V AC0 AA30 kVA€8,455.49
A
X48M28T1516CUNON		208Y/120V28"480VCopper150°C480-208/120V AC0 AA15 kVA€8,088.74
A
X48M47F4516CUNON		277/480V39.18"480VCopper115°C277/480V AC0 AA45 kVA€14,751.99
A
X29M47T75CU16NON		277/480V43"208VCopper150°C208-480/277V0 AA75 kVA€23,182.24
A
X48M47F4516CUPOS		277/480V39.18"480VCopper115°C277/480V AC15 AA45 kVA€14,751.99

Features

  • They feature electromagnetic flux cancellation for harmonic mitigating.
  • These transformers are available in 0 / -30 / +15 / -15 degrees phase shift, allowing flexibility to target specific families of harmonics.
  • They are equipped with a bonding / grounding bar fixed to the bottom panel for enhanced performance and safety by providing a safe path for electrical current to flow to the ground.
  • These harmonic mitigating transformers come in copper windings variants for efficient current transmission.
  • They further feature NEMA 2 Enclosure for providing a degree of protection from falling dirt and dripping.

Standards and Approvals

  • UL

Frequently Asked Questions

What is the frequency rating of Eaton harmonic mitigating transformers?

60 Hz.

In what kVA ratings are these harmonic mitigating transformers offered?

They are available in 15, 30, 45, 75, 112.5, 150, 225, 300 and 500kV
