EATON CAH Series Molded Case Circuit Breakers


Eaton CAH Series MCCBs are ideal for accurate tripping to overcurrent conditions for preventing power outages and equipment used in commercial and industrial applications.

Filter
EATON CAH2150A
EATON CAH2100B
EATON CAH2125C
EATON CAH2175D
EATON CAH3125E
EATON CAH3150F
EATON CAH3100G
StyleModelNumber Of PolesVoltage TypeFrame TypeVoltageAic RatingPrice
A
CAH2150		2ACCA240V22 kAIC @ 240V-
RFQ
B
CAH2100		2ACCA240V22 kAIC @ 240V€3,606.80
C
CAH2125		2ACCA240V22 kAIC @ 240V€3,606.80
D
CAH2175		2ACCA240V22 kAIC @ 240V€3,606.80
A
CAH2200		2ACCA240V22 kAIC @ 240V-
RFQ
A
CAH2225		2ACCA240V22 kAIC @ 240V€3,091.54
RFQ
A
CAH3200		3ACCA240V22 kAIC @ 240V-
RFQ
E
CAH3125		3ACCA240V22 kAIC @ 240V-
RFQ
F
CAH3150		3ACCA240V22 kAIC @ 240V€4,345.78
A
CAH3175		3ACCA240V22 kAIC @ 240V€4,035.37
RFQ
A
CAH3225		3ACCA240V22 kAIC @ 240V-
RFQ
G
CAH3100		3ACCA240V22 kAIC @ 240V-
RFQ

CAH Series Molded Case Circuit Breakers

Eaton CAH Series circuit breakers are designed for protection from short circuit and overcurrent conditions. They have a thermal magnetic trip unit that offers both instantaneous and time-delayed current limiting protection, bolt-on mounting to ensure easy installation & repair, and load end terminals for passing power to devices along the circuit. The CA frame design provides an interrupting rating of 22kA @ 240V and current ratings up to 225A for reverse feed applications. These UL listed circuit breakers are available in 2 and 3 pole options on Raptor Supplies.

Features

  • Eaton CAH Series MCCBs feature I.C. thermal-magnetic trip for dual protection against both overheating and overcurrent conditions.
  • These MCCBs are preinstalled with line and load terminals for a secure connection, ensuring safety.
  • They further provide a continuous current rating of 100A, 125A, 150A, 175A, 200A & 225A at 40 degrees C.

Compatible Accessories

  • Handle Locks (Padlocks & Non-Padlocks): These locks are used to prevent the handle of the MCCB from moving to the OFF position, ensuring safety and easy maintenance.

Frequently Asked Questions

What is the advantage of the installed line and load terminals in Eaton CAH Series MCCBs?

The line & load terminals are easy to install and remove, thus providing a quick installation for the breaker.
