Associated Spring Raymond Gas Springs And Dampers

ASSOCIATED SPRING RAYMOND -

EP2 16 Gas Springs

A

ASSOCIATED SPRING RAYMOND EP2 16x2-030-GR

B

Style	Model	Force	Cylinder Dia.	Compressed Length	Extended Length	Rod Dia.	Locking	Fixed Resistance	Rod Thread Size	Price
A	EP2 16x2-080-GR	13 lbs.	0.62"	4.93"	8.07"	-	No	No	M16 x 1.5	€239.27
A	EP2 16-100-GR	20 lbf.	0.62"	145 mm	245 mm	6 mm	No	No	M16 x 1.5	€277.09
B	EP2 16x2-030-GR	20 lbf.	0.62"	75 mm	105 mm	6 mm	No	No	M16 x 1.5	€204.18
A	EP2 16x2-020-GR	20 lbf.	0.62"	65 mm	85 mm	6 mm	No	No	M16 x 1.5	€188.21
A	EP2 16-040-GR	20 lbf.	0.62"	85 mm	-	6 mm	No	No	M16 x 1.5	€240.64
B	EP2 16x2-070-GR	20 lbf.	0.62"	115 mm	185 mm	6 mm	No	No	M16 x 1.5	€226.51
A	EP2 16-030-GR	20 lbf.	0.62"	75 mm	105 mm	6 mm	No	No	M16 x 1.5	€248.63
A	EP2 16x2-125-GR	20 lbf.	0.62"	170 mm	295 mm	6 mm	No	No	M16 x 1.5	€245.68
A	EP2 16x2-050-GR	20 lbf.	0.62"	95 mm	145 mm	6 mm	No	No	M16 x 1.5	€216.92
A	EP2 16x2-100-GR	20 lbf.	0.62"	145 mm	245 mm	6 mm	No	No	M16 x 1.5	€242.45
A	EP2 16-080-GR	20 lbf.	0.62"	125 mm	205 mm	6 mm	No	No	M16 x 1.5	€273.45
A	EP2 16-020-GR	20 lbf.	0.62"	65 mm	85 mm	6 mm	No	No	M16 x 1.5	€215.10
B	EP2 16x2-060-GR	20 lbf.	0.62"	105 mm	165 mm	6 mm	No	No	M16 x 1.5	€231.86
A	EP2 16-050-GR	20 lbf.	0.62"	95 mm	145 mm	6 mm	No	No	M16 x 1.5	€247.91
B	EP2 16x2-010-GR	20 lbf.	0.62"	55 mm	65 mm	6 mm	No	No	M16 x 1.5	€191.56
A	EP2 16-070-GR	20 lbf.	0.62"	115 mm	185 mm	6 mm	No	No	M16 x 1.5	€258.88
A	EP2 16x2-040-GR	20 lbf.	0.62"	85 mm	125 mm	6 mm	No	No	M16 x 1.5	€221.94
A	EP2 16-060-GR	20 lbf.	0.62"	105 mm	165 mm	6 mm	No	No	M16 x 1.5	€270.30
A	EP2 16-010-GR	20 lbf.	0.62"	55 mm	65 mm	6 mm	No	No	M16 x 1.5	€209.12
A	EP2 16-125-GR	20 lbf.	0.62"	170 mm	295 mm	6 mm	No	No	M16 x 1.5	€280.77
A	EP2 16-020-BL	25 lbs.	0.62"	2 14/25"	3.35"	-	No	No	M16 x 1.5	€215.10
A	EP2 16-100-BL	25 lbs.	0.62"	5 17/25"	9.65"	-	No	No	M16 x 1.5	€242.45
A	EP2 16-040-BL	40 lbf.	0.62"	85 mm	125 mm	6 mm	No	No	M16 x 1.5	€210.56
A	EP2 16-060-BL	40 lbf.	0.62"	105 mm	165 mm	6 mm	No	No	M16 x 1.5	€236.51
A	EP2 16x2-125-BL	40 lbf.	0.62"	170 mm	295 mm	6 mm	No	No	M16 x 1.5	€245.68

ASSOCIATED SPRING RAYMOND -

R12 Gas Springs

A

B

C

D

E

Style	Model	Cylinder Dia.	Rod Dia.	Force	Compressed Length	Extended Length	Locking	Fixed Resistance	Finish	Price
A	R12-019-BK	0.47"	6/25"	155 lbf.	2 3/8"	3 1/8"	No	No	Black Oxide	€176.22
B	R12-075-RE	0.47"	6/25"	133 lbf.	4 11/16"	7 19/32"	No	No	Black Oxide	€195.50
B	R12-125-RE	0.47"	6/25"	137 lbf.	6 5/8"	11 1/2"	No	No	Black Oxide	€210.35
B	R12-015-RE	0.47"	6/25"	113 lbf.	2 7/32"	2 51/64"	No	No	Black Oxide	€159.28
A	R12-025-BK	0.47"	6/25"	-	2 39/64"	3 37/64"	No	No	Black Oxide	€168.51
C	R12-038-GR	0.47"	6/25"	41 lbf.	3 1/8"	4 19/32"	No	No	Black Oxide	€172.33
D	R12-050-YE	0.47"	6/25"	167 lbf.	3 37/64"	5 17/32"	No	No	Black Oxide	€170.86
E	R12-075-BL	0.47"	6/25"	89 lbf.	-	-	No	No	Black Oxide	€199.36
D	R12-080-YE	0.47"	6/25"	186 lbf.	4 7/8"	7 63/64"	No	No	Black Oxide	€179.09
C	R12-125-GR	0.47"	6/25"	45 lbf.	6 5/8"	11 1/2"	No	No	Black Oxide	€203.80
B	R12-080-RE	0.47"	6/25"	139 lbf.	4 7/8"	7 63/64"	No	No	Black Oxide	€192.47
E	R12-125-BL	0.47"	6/25"	91 lbf.	6 5/8"	11 1/2"	No	No	Black Oxide	€210.35
E	R12-010-BL	0.47"	6/25"	71 lbf.	2 1/64"	2 13/32"	No	No	Black Oxide	€160.52
B	R12-012-RE	0.47"	6/25"	111 lbf.	2 1/8"	2 5/8"	No	No	Black Oxide	€168.43
E	R12-063-BL	0.47"	6/25"	89 lbf.	4 15/64"	6 45/64"	No	No	Black Oxide	€197.86
D	R12-125-YE	0.47"	6/25"	182 lbf.	6 5/8"	11 1/2"	No	No	Black Oxide	€210.35
C	R12-075-GR	0.47"	6/25"	44 lbf.	4 11/16"	7 19/32"	No	No	Black Oxide	€194.43
D	R12-007-YE	0.47"	6/25"	134 lbf.	1 29/32"	2 3/16"	No	No	Black Oxide	€157.25
E	R12-012-BL	0.47"	6/25"	74 lbf.	2 1/8"	2 5/8"	No	-	Black Oxide	€168.59
C	R12-007-GR	0.47"	6/25"	34 lbf.	1 29/32"	2 3/16"	No	No	Black Oxide	€157.25
D	R12-010-YE	0.47"	6/25"	143 lbf.	2 1/64"	2 13/32"	No	No	Black Oxide	€169.89
E	R12-015-BL	0.47"	6/25"	75 lbf.	2 7/32"	2 51/64"	No	No	Black Oxide	€159.28
B	R12-019-RE	0.47"	6/25"	116 lbf.	2 3/8"	3 1/8"	No	No	Black Oxide	€180.28
A	R12-038-BK	0.47"	6/25"	164 lbf.	3 1/8"	4 19/32"	No	No	Black Oxide	€170.72
C	R12-050-GR	0.47"	6/25"	42 lbf.	3 37/64"	5 17/32"	No	No	Black Oxide	€170.86

ASSOCIATED SPRING RAYMOND -

Powerline X320 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X320-038	720 lbs.	2 17/25"	4.09"	1"	-	No	No	No	€250.13
A	X320-125	720 lbs.	6.31"	11.22"	1"	-	No	No	No	€318.71
B	X320-010	720 lbs.	1 14/25"	1.97"	1"	-	No	No	No	€235.02
A	X320-007	1080 lbf.	1 7/16"	1 45/64"	1"	15 mm	No	No	No	€227.41
A	X320-019	1150 lbf.	1 29/32"	2 21/32"	1"	15 mm	No	No	No	€242.61
A	X320-015	1150 lbf.	1 3/4"	2 11/32"	1"	15 mm	No	No	No	€238.78
B	X320-025	1170 lbf.	2 9/64"	3 1/8"	1"	15 mm	No	No	No	€249.64
A	X320-075	1190 lbf.	4 19/64"	7 13/64"	1"	15 mm	No	No	No	€272.90
A	X320-100	1190 lbf.	5 17/64"	9 5/32"	1"	15 mm	No	No	No	€295.71
A	X320-080	1190 lbf.	4 31/64"	7 19/32"	1"	15 mm	No	No	No	€269.74
B	X320-063	1190 lbf.	3 5/8"	6 5/64"	1"	15 mm	No	No	No	€261.53
A	X320-050	1190 lbf.	3 1/8"	5 1/16"	1"	15 mm	No	No	No	€253.99

ASSOCIATED SPRING RAYMOND -

TM 250 Gas Springs, Metric

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Finish	Price
A	TM 250-012	765 lbf.	62.703125 mm	75.4 mm	1.37"	15 mm	No	No	Black Oxide	€337.29
B	TM 250-050	765 lbf.	3 29/32"	5 27/32"	1.37"	15 mm	No	No	Black Oxide	€420.65
B	TM 250-038	765 lbf.	3 7/16"	4 59/64"	1.37"	15 mm	No	No	Black Oxide	€397.87
B	TM 250-025	765 lbf.	2 59/64"	3 29/32"	1.37"	15 mm	No	No	Black Oxide	€386.57
B	TM 250-100	790 lbf.	5 27/32"	9 3/4"	1.37"	15 mm	No	No	Black Oxide	€464.45
B	TM 250-080	790 lbf.	5 1/16"	8 3/16"	1.37"	15 mm	No	No	Black Oxide	€473.69
A	TM 250-063	790 lbf.	4 27/64"	6 29/32"	1.37"	15 mm	No	No	Black Oxide	€451.01

ASSOCIATED SPRING RAYMOND -

TU 750 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	TU 750-025	2700 lbf.	4 11/16"	5 21/32"	2"	25 mm	No	No	No	€715.13
A	TU 750-038	2700 lbf.	5 3/16"	6 43/64"	2"	25 mm	No	No	No	€734.69
A	TU 750-050	2700 lbf.	5 21/32"	7 19/32"	2"	25 mm	No	No	No	€759.73
B	TU 750-100	2700 lbf.	7 19/32"	11 1/2"	2"	25 mm	No	No	No	€806.66
A	TU 750-012	2700 lbf.	4 13/64"	4 11/16"	50.2 mm	25 mm	No	No	No	€698.20
A	TU 750-080	2700 lbf.	6 13/16"	9 15/16"	2"	25 mm	No	No	No	€789.69
A	TU 750-063	2700 lbf.	6 3/16"	8 21/32"	2"	25 mm	No	No	No	€772.69
A	TU 750-160	2720 lbf.	9 15/16"	16 3/16"	2"	25 mm	No	No	No	€843.85
A	TU 750-200	2720 lbf.	11 1/2"	19 19/64"	2"	25 mm	No	No	No	€888.83
A	TU 750-125	2720 lbf.	8 37/64"	13 29/64"	2"	25 mm	No	No	No	€822.21
A	TU 750-300	2720 lbf.	15 13/32"	27 3/32"	2"	25 mm	No	No	No	€962.41
A	TU 750-250	2720 lbf.	13 29/64"	23 13/64"	2"	25 mm	No	No	No	€932.49

ASSOCIATED SPRING RAYMOND -

TU 7500 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	TU 7500-125	16860 lbs.	11"	15.94"	5.93"	-	No	No	No	€2,583.76
A	TU 7500-025	23600 lbf.	180 mm	205 mm	5.93"	80 mm	No	No	No	€2,135.27
A	TU 7500-038	24730 lbf.	193.09375 mm	231.2 mm	5.93"	80 mm	No	No	No	€2,198.26
A	TU 7500-050	25400 lbf.	205 mm	255 mm	5.93"	80 mm	No	No	No	€2,261.23
A	TU 7500-063	25850 lbf.	218.5 mm	282 mm	5.93"	80 mm	No	No	No	€2,271.79
A	TU 7500-080	26300 lbf.	235 mm	315 mm	5.93"	80 mm	No	No	No	€2,333.55
A	TU 7500-100	26750 lbf.	255 mm	355 mm	5.93"	80 mm	No	No	No	€2,457.04
A	TU 7500-160	27430 lbf.	315 mm	475 mm	5.93"	80 mm	No	No	No	€2,700.77
A	TU 7500-200	27650 lbf.	355 mm	555 mm	5.93"	80 mm	No	No	No	€2,924.99
B	TU 7500-250	27880 lbf.	405 mm	655 mm	5.93"	80 mm	No	No	No	€3,159.01
A	TU 7500-300	27880 lbf.	455 mm	755 mm	5.93"	80 mm	No	No	No	€3,170.86

ASSOCIATED SPRING RAYMOND -

Powerline X1500 Gas Springs

A

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Adjustable Resistance	Rod Thread Size	Price
A	X1500-080	3375 lbs.	4.87"	8"	2 1/2"	-	No	No	M6	€816.34
A	X1500-032	5355 lbf.	2 61/64"	4 13/64"	2 1/2"	36 mm	No	No	M6	€730.87
A	X1500-025	5365 lbf.	2 11/16"	3 21/32"	2 1/2"	36 mm	No	No	M6	€752.51
A	X1500-038	5375 lbf.	3 3/16"	4 11/16"	2 1/2"	36 mm	No	No	M6	€759.66
A	X1500-050	5395 lbf.	3 21/32"	5 39/64"	2 1/2"	36 mm	No	No	M6	€784.82
A	X1500-013	5395 lbf.	2 7/32"	2 47/64"	2 1/2"	36 mm	No	No	M6	€731.29
A	X1500-063	5420 lbf.	4 11/64"	6 5/8"	2 1/2"	36 mm	No	No	M6	€794.10
A	X1500-016	5420 lbf.	2 11/32"	2 61/64"	2 1/2"	36 mm	No	No	M6	€742.77
A	X1500-019	5440 lbf.	2 29/64"	3 3/16"	2 1/2"	36 mm	No	No	M6	€720.84
A	X1500-075	5440 lbf.	4 41/64"	7 9/16"	2 1/2"	36 mm	No	No	M6	€792.66
A	X1500-125	5465 lbf.	6 19/32"	11 29/64"	2 1/2"	36 mm	No	No	M6	€826.36
A	X1500-100	5465 lbf.	5 39/64"	9 33/64"	2 1/2"	36 mm	No	No	M6	€833.86

ASSOCIATED SPRING RAYMOND -

Powerline X170 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X170-050	382 lbs.	3 3/25"	5 3/25"	3/4"	-	No	No	No	€219.88
A	X170-019	630 lbf.	1 29/32"	2 21/32"	3/4"	11 mm	No	No	No	€197.11
A	X170-125	630 lbf.	6 15/64"	11 7/64"	3/4"	11 mm	No	No	No	€248.32
B	X170-025	630 lbf.	2 9/64"	3 1/8"	3/4"	11 mm	No	No	No	€198.20
B	X170-010	630 lbf.	1 9/16"	1 61/64"	3/4"	11 mm	No	No	No	€189.52
B	X170-080	630 lbf.	4 31/64"	7 19/32"	3/4"	11 mm	No	No	No	€246.25
B	X170-007	630 lbf.	1 7/16"	1 45/64"	3/4"	11 mm	No	No	No	€181.89
B	X170-075	630 lbf.	4 19/64"	7 13/64"	3/4"	11 mm	No	No	No	€228.23
A	X170-063	630 lbf.	3 5/8"	6 5/64"	3/4"	11 mm	No	No	No	€224.07
A	X170-038	630 lbf.	2 21/32"	4 1/8"	3/4"	11 mm	No	No	No	€212.25
B	X170-015	630 lbf.	1 3/4"	2 11/32"	3/4"	11 mm	No	No	No	€193.26
A	X170-100	630 lbf.	5 17/64"	9 5/32"	3/4"	11 mm	No	No	No	€253.99

ASSOCIATED SPRING RAYMOND -

Powerline X2400 Gas Springs

A

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X2400-016	8611 lbf.	2 3/8"	3"	2.93"	45 mm	No	No	No	€869.72
A	X2400-038	8633 lbf.	3 15/64"	4 45/64"	2.93"	45 mm	No	No	No	€928.43
A	X2400-019	8656 lbf.	2 31/64"	3 15/64"	2.93"	45 mm	No	No	No	€898.40
A	X2400-032	8678 lbf.	3"	4 1/4"	2.93"	45 mm	No	No	No	€946.84
A	X2400-025	8701 lbf.	2 47/64"	3 45/64"	2.93"	45 mm	No	No	No	€907.46
A	X2400-075	8813 lbf.	4 11/16"	7 19/32"	2.93"	45 mm	No	No	No	€967.00
A	X2400-063	8813 lbf.	4 13/64"	6 21/32"	2.93"	45 mm	No	No	No	€949.69
A	X2400-080	8813 lbf.	4 7/8"	7 63/64"	2.93"	45 mm	No	No	No	€974.01
A	X2400-050	8813 lbf.	3 45/64"	5 21/32"	2.93"	45 mm	No	No	No	€932.07
A	X2400-100	8835 lbf.	5 21/32"	9 35/64"	2.93"	45 mm	No	No	No	€950.29
A	X2400-125	8835 lbf.	6 5/8"	11 1/2"	2.93"	45 mm	No	No	No	€1,044.06

ASSOCIATED SPRING RAYMOND -

Powerline X350 Gas Springs

A

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X350-010	810 lbs.	1 14/25"	1.97"	1 1/4"	-	No	No	No	€248.32
A	X350-013	1190 lbf.	1 43/64"	2 3/16"	1 1/4"	16 mm	No	No	No	€265.29
A	X350-080	1240 lbf.	4 19/64"	7 13/32"	1 1/4"	16 mm	No	No	No	€336.14
A	X350-100	1240 lbf.	5 1/16"	8 31/32"	1 1/4"	16 mm	No	No	No	€352.45
A	X350-125	1240 lbf.	6 3/64"	10 59/64"	1 1/4"	16 mm	No	No	No	€371.85
A	X350-038	1240 lbf.	2 21/32"	4 1/8"	1 1/4"	16 mm	No	No	No	€288.00
A	X350-075	1260 lbf.	4 3/32"	7 1/64"	1 1/4"	16 mm	No	No	No	€333.56
A	X350-032	1260 lbf.	2 13/32"	3 21/32"	1 1/4"	16 mm	No	No	No	€280.44
A	X350-063	1260 lbf.	3 5/8"	6 5/64"	1 1/4"	16 mm	No	No	No	€306.97
A	X350-050	1260 lbf.	3 1/8"	5 1/16"	1 1/4"	16 mm	No	No	No	€301.42
A	X350-019	1260 lbf.	1 29/32"	2 21/32"	1 1/4"	16 mm	No	No	No	€272.90
A	X350-025	1260 lbf.	2 9/64"	3 1/8"	1 1/4"	16 mm	No	No	No	€271.20

ASSOCIATED SPRING RAYMOND -

R19 Gas Springs

A

B

C

D

E

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Finish	Fixed Resistance	Price
A	R19-050-BK	67 lbs. to 202 lbs.	3.62"	5.59"	3/4"	0.31"	No	Black Oxide	No	€191.43
B	R19-125-GR	92 lbf.	6 5/8"	11 1/2"	3/4"	0.31"	No	Black Oxide	No	€256.93
B	R19-050-GR	92 lbf.	3 37/64"	5 17/32"	3/4"	0.31"	No	Black Oxide	No	€188.40
B	R19-100-GR	92 lbf.	5 21/32"	9 35/64"	3/4"	0.31"	No	Black Oxide	No	€232.79
B	R19-080-GR	92 lbf.	4 7/8"	7 63/64"	3/4"	0.31"	No	Black Oxide	No	€214.49
B	R19-063-GR	92 lbf.	4 15/64"	6 45/64"	3/4"	0.31"	No	Black Oxide	No	€212.51
B	R19-038-GR	92 lbf.	3 1/8"	4 19/32"	3/4"	0.31"	No	Black Oxide	No	€192.47
B	R19-025-GR	94 lbf.	2 39/64"	3 37/64"	3/4"	0.31"	No	Black Oxide	No	€172.43
B	R19-015-GR	99 lbf.	2 7/32"	2 51/64"	3/4"	0.31"	No	Black Oxide	No	€176.19
B	R19-010-GR	105 lbf.	2 1/64"	2 13/32"	3/4"	0.31"	No	Black Oxide	No	€168.03
B	R19-007-GR	119 lbf.	1 29/32"	2 3/16"	3/4"	0.31"	No	Black Oxide	No	€156.98
C	R19-100-BL	152 lbf.	5 21/32"	9 35/64"	3/4"	0.31"	No	Black Oxide	No	€234.03
C	R19-125-BL	152 lbf.	6 5/8"	11 1/2"	3/4"	0.31"	No	Black Oxide	No	€253.15
C	R19-080-BL	152 lbf.	4 7/8"	7 63/64"	3/4"	0.31"	No	Black Oxide	No	€206.45
C	R19-063-BL	152 lbf.	4 15/64"	6 45/64"	3/4"	0.31"	No	Black Oxide	No	€229.25
C	R19-050-BL	152 lbf.	3 37/64"	5 17/32"	3/4"	0.31"	No	Black Oxide	No	€188.40
C	R19-038-BL	155 lbf.	3 1/8"	4 19/32"	3/4"	8 mm	No	Black Oxide	No	€178.88
C	R19-025-BL	157 lbf.	2 39/64"	3 37/64"	3/4"	0.31"	No	Black Oxide	No	€172.43
C	R19-015-BL	164 lbf.	2 7/32"	2 51/64"	3/4"	0.31"	No	Black Oxide	No	€163.74
C	R19-010-BL	175 lbf.	2 1/64"	2 13/32"	3/4"	0.31"	No	Black Oxide	No	€171.28
C	R19-007-BL	199 lbf.	1 29/32"	2 3/16"	3/4"	0.31"	No	Black Oxide	No	€156.98
D	R19-100-YE	202 lbs.	5.71"	9.65"	3/4"	0.31"	No	Black Oxide	No	€248.63
E	R19-063-RE	214 lbf.	4 15/64"	6 45/64"	3/4"	0.31"	No	Black Oxide	No	€211.30
E	R19-125-RE	214 lbf.	6 5/8"	11 1/2"	3/4"	0.31"	No	Black Oxide	No	€262.15
E	R19-100-RE	214 lbf.	5 21/32"	9 35/64"	3/4"	0.31"	No	Black Oxide	No	€234.03

ASSOCIATED SPRING RAYMOND -

Powerline X4200 Gas Springs

A

B

Style	Model	Force	Extended Length	Cylinder Dia.	Compressed Length	Rod Dia.	Fixed Resistance	Adjustable Resistance	Rod Thread Size	Price
A	X4200-025	9440 lbs.	4 1/4"	3 3/4"	3 1/4"	-	No	No	M8	€1,170.21
B	X4200-016	13870 lbf.	3 33/64"	3 3/4"	-	60 mm	No	No	M8	€1,167.06
B	X4200-019	14320 lbf.	3 47/64"	3 3/4"	3"	60 mm	No	No	M8	€1,123.58
B	X4200-032	14680 lbf.	4 3/4"	3 3/4"	3 33/64"	60 mm	No	No	M8	€1,174.19
B	X4200-038	14790 lbf.	5 7/32"	3 3/4"	3 47/64"	60 mm	No	No	M8	€1,198.25
B	X4200-050	15060 lbf.	6 5/32"	3 3/4"	4 13/64"	60 mm	No	No	M8	€1,181.20
B	X4200-063	15240 lbf.	7 11/64"	3 3/4"	4 45/64"	60 mm	No	No	M8	€1,269.37
B	X4200-075	15285 lbf.	8 7/64"	3 3/4"	5 3/16"	60 mm	No	No	M8	€1,280.02
B	X4200-080	15420 lbf.	8 1/2"	3 3/4"	5 3/8"	60 mm	No	No	M8	€1,226.66
B	X4200-100	15535 lbf.	10 1/16"	3 3/4"	6 5/32"	60 mm	No	No	M8	€1,240.34
B	X4200-125	15645 lbf.	12 1/64"	3 3/4"	7 1/8"	60 mm	No	No	M8	€1,294.69

ASSOCIATED SPRING RAYMOND -

Powerline X500 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X500-016	1060 lbs.	1.81"	2 11/25"	1 1/2"	-	No	No	No	€371.85
A	X500-075	1060 lbs.	4 3/25"	7.09"	1 1/2"	-	No	No	No	€454.75
A	X500-080	1600 lbf.	4 19/64"	7 13/32"	1 1/2"	20 mm	No	No	No	€472.85
A	X500-013	1600 lbf.	1 43/64"	2 3/16"	1 1/2"	20 mm	No	No	No	€350.83
A	X500-100	1600 lbf.	5 1/16"	8 31/32"	1 1/2"	20 mm	No	No	No	€466.45
A	X500-125	1600 lbf.	6 3/64"	10 59/64"	1 1/2"	20 mm	No	No	No	€472.29
A	X500-010	1620 lbf.	1 9/16"	1 61/64"	1 1/2"	20 mm	No	No	No	€367.58
A	X500-032	1620 lbf.	2 13/32"	3 21/32"	1 1/2"	20 mm	No	No	No	€405.44
A	X500-063	1620 lbf.	3 5/8"	6 5/64"	1 1/2"	20 mm	No	No	No	€439.01
B	X500-050	1620 lbf.	3 1/8"	5 1/16"	1 1/2"	20 mm	No	No	No	€445.50
A	X500-038	1620 lbf.	2 21/32"	4 1/8"	1 1/2"	20 mm	No	No	No	€418.28
A	X500-025	1640 lbf.	2 9/64"	3 1/8"	1 1/2"	20 mm	No	No	No	€400.92
A	X500-019	1660 lbf.	1 29/32"	2 21/32"	1 1/2"	20 mm	No	No	No	€394.15

ASSOCIATED SPRING RAYMOND -

CU1000 Gas Springs

A

Style	Model	Compressed Length	Extended Length	Cylinder Dia.	Force	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	CU 1000-032	135 mm	167 mm	1 1/2"	3595 lbf.	20 mm	No	No	No	€681.62
A	CU 1000-040	155 mm	195 mm	1 1/2"	3595 lbf.	20 mm	No	No	No	€662.87
A	CU 1000-050	180 mm	230 mm	1 1/2"	3595 lbf.	20 mm	No	No	No	€712.05

ASSOCIATED SPRING RAYMOND -

TI 250 Gas Springs, Inch

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	TI 250-012	765 lbf.	2 7/16"	2 15/16"	1.37"	15 mm	No	No	No	€337.29
B	TI 250-050	765 lbf.	3 29/32"	5 27/32"	1.37"	15 mm	No	No	No	€416.29
A	TI 250-025	765 lbf.	2 59/64"	3 29/32"	1.37"	15 mm	No	No	No	€390.30
A	TI 250-038	765 lbf.	3 7/16"	4 59/64"	1.37"	15 mm	No	No	No	€393.37
A	TI 250-100	790 lbf.	5 27/32"	9 3/4"	1.37"	15 mm	No	No	No	€482.63
A	TI 250-080	790 lbf.	5 1/16"	8 3/16"	1.37"	15 mm	No	No	No	€473.69
B	TI 250-063	790 lbf.	4 27/64"	6 29/32"	1.37"	15 mm	No	No	No	€451.01

ASSOCIATED SPRING RAYMOND -

M2 Gas Springs

A

B

Style	Model	Force	Compressed Length	Cylinder Dia.	Extended Length	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	M2-016-GR	110 lbs.	2 1/4"	1"	2.91"	-	No	No	No	€209.12
A	M2-063-GR	171 lbf.	4 15/64"	1"	6 45/64"	12 mm	No	No	No	€247.33
B	M2-100-GR	171 lbf.	5 21/32"	1"	9 35/64"	12 mm	No	No	No	€262.38
B	M2-125-GR	171 lbf.	6 5/8"	1"	11 1/2"	12 mm	No	No	No	€277.10
A	M2-012-GR	173 lbf.	2 1/8"	1"	2 5/8"	12 mm	No	No	No	€203.44
B	M2-010-GR	173 lbf.	2 1/64"	1"	2 13/32"	12 mm	No	No	No	€213.70
B	M2-125-BL	225 lbs.	6 17/25"	1"	11.61"	-	No	No	No	€298.94
A	M2-063-BL	342 lbf.	4 15/64"	1"	6 45/64"	12 mm	No	No	No	€247.77
B	M2-100-BL	342 lbf.	5 21/32"	1"	9 35/64"	12 mm	No	No	No	€261.07
B	M2-012-BL	344 lbf.	2 1/8"	1"	2 5/8"	12 mm	No	No	No	€203.44
B	M2-010-BL	344 lbf.	2 1/64"	1"	2 13/32"	12 mm	No	No	No	€200.45
A	M2-016-BL	346 lbf.	2 17/64"	1"	2 7/8"	12 mm	No	No	No	€206.42
B	M2-012-YL	450 lbf.	2 1/8"	1"	2 21/32"	12 mm	No	No	No	€212.25
B	M2-125-YL	450 lbf.	170 mm	1"	295 mm	12 mm	No	No	No	€288.00
B	M2-010-YL	450 lbf.	52 mm	1"	62 mm	12 mm	No	No	No	€208.43
B	M2-100-YE	450 lbs.	5 17/25"	1"	9.65"	-	No	No	No	€261.07
A	M2-063-BK	679 lbf.	4 15/64"	1"	6 45/64"	12 mm	No	No	-	€247.33
A	M2-063-RE	679 lbf.	4 15/64"	1"	6 45/64"	12 mm	No	No	No	€265.92
A	M2-063-YE	679 lbf.	4 15/64"	1"	-	12 mm	No	No	No	€247.33
B	M2-100-BK	686 lbf.	5 21/32"	1"	9 35/64"	12 mm	No	No	No	€262.38
B	M2-100-RE	686 lbf.	5 21/32"	1"	9 35/64"	12 mm	No	No	No	€262.38
B	M2-010-RE	689 lbf.	2 1/64"	1"	2 13/32"	12 mm	No	No	No	€200.45
B	M2-010-BK	689 lbf.	2 1/64"	1"	2 13/32"	12 mm	No	No	No	€199.35
B	M2-125-BK	689 lbf.	6 5/8"	1"	11 1/2"	12 mm	No	No	No	€298.94
B	M2-125-RE	689 lbf.	6 5/8"	1"	11 1/2"	12 mm	No	No	No	€277.10

ASSOCIATED SPRING RAYMOND -

CU1800 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	CU 1800-010	5845 lbf.	70 mm	80 mm	2"	30 mm	No	No	No	€820.72
A	CU 1800-032	6070 lbf.	130 mm	162 mm	2"	30 mm	No	No	No	€902.51
B	CU 1800-040	6295 lbf.	150 mm	190 mm	2"	30 mm	No	No	No	€923.36
B	CU 1800-050	6520 lbf.	170 mm	220 mm	2"	30 mm	No	No	No	€951.68

ASSOCIATED SPRING RAYMOND -

Powerline X750 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	X750-032	1665 lbs.	2 1/2"	3.78"	1 3/4"	-	No	No	No	€548.19
A	X750-019	2630 lbf.	1 63/64"	2 47/64"	1 3/4"	25 mm	No	No	No	€532.36
A	X750-038	2650 lbf.	2 47/64"	4 13/64"	1 3/4"	25 mm	No	No	No	€577.82
A	X750-025	2650 lbf.	2 7/32"	3 3/16"	1 3/4"	25 mm	No	No	No	€543.91
A	X750-063	2650 lbf.	3 45/64"	6 5/32"	1 3/4"	25 mm	No	No	No	€585.23
B	X750-050	2650 lbf.	3 3/16"	5 9/64"	1 3/4"	25 mm	No	No	No	€580.24
A	X750-080	2675 lbf.	4 23/64"	7 31/64"	1 3/4"	25 mm	No	No	No	€626.24
A	X750-075	2675 lbf.	4 11/64"	7 3/32"	1 3/4"	25 mm	No	No	No	€586.96
A	X750-125	2675 lbf.	6 1/8"	10 63/64"	1 3/4"	25 mm	No	No	No	€682.50
A	X750-100	2675 lbf.	5 9/64"	9 3/64"	1 3/4"	25 mm	No	No	No	€638.74
A	X750-010	2720 lbf.	1 5/8"	2 1/64"	1 3/4"	25 mm	No	No	No	€521.32
A	X750-013	2720 lbf.	1 3/4"	2 17/64"	1 3/4"	25 mm	No	No	No	€503.33
A	X750-016	2720 lbf.	1 7/8"	2 31/64"	1 3/4"	25 mm	No	No	No	€518.10

ASSOCIATED SPRING RAYMOND -

TU 10000 Gas Springs

A

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Rod Thread Size	Price
A	TU 10000-025	31020 lbf.	7 13/64"	8 3/16"	7 17/25"	95 mm	No	No	M16	€4,318.04
A	TU 10000-038	32150 lbf.	7 23/32"	9 13/64"	7 17/25"	95 mm	No	No	M16	€4,467.11
A	TU 10000-050	33050 lbf.	8 3/16"	10 9/64"	7 17/25"	95 mm	No	No	M16	€4,586.87
A	TU 10000-063	33720 lbf.	8 45/64"	11 3/16"	7 17/25"	95 mm	No	No	M16	€4,648.83
A	TU 10000-080	34170 lbf.	9 23/64"	12 31/64"	7 17/25"	95 mm	No	No	M16	€4,767.68
A	TU 10000-100	35070 lbf.	10 9/64"	14 3/64"	7 17/25"	95 mm	No	No	M16	€4,753.17
A	TU 10000-125	35300 lbf.	11 7/64"	15 63/64"	7 17/25"	95 mm	No	No	M16	€4,899.19
A	TU 10000-160	35520 lbf.	12 31/64"	18 23/32"	7 17/25"	95 mm	No	No	M16	€5,170.37
A	TU 10000-200	35970 lbf.	14 3/64"	21 27/32"	7 17/25"	95 mm	No	No	M16	€5,289.57
A	TU 10000-300	35970 lbf.	17 15/16"	29 41/64"	7 17/25"	95 mm	No	No	M16	€5,528.01
A	TU 10000-250	35970 lbf.	15 63/64"	25 47/64"	7 17/25"	95 mm	No	No	M16	€5,423.66

ASSOCIATED SPRING RAYMOND -

TU 1500 Gas Springs

A

Style	Model	Extended Length	Cylinder Dia.	Compressed Length	Force	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	TU 1500-025	6 15/64"	2.93"	-	5170 lbf.	36 mm	No	No	No	€968.42
A	TU 1500-038	7 17/64"	2.93"	5 49/64"	5170 lbf.	36 mm	No	No	No	€990.95
A	TU 1500-050	8 3/16"	2.93"	6 15/64"	5170 lbf.	36 mm	No	No	No	€1,015.91
A	TU 1500-063	9 15/64"	2.93"	6 49/64"	5170 lbf.	36 mm	No	No	No	€1,044.06
A	TU 1500-080	10 17/32"	2.93"	7 13/32"	5170 lbf.	36 mm	No	No	No	€1,061.63
A	TU 1500-100	12 3/32"	2.93"	8 3/16"	5170 lbf.	36 mm	No	No	No	€985.54
A	TU 1500-125	14 3/64"	2.93"	9 5/32"	5170 lbf.	36 mm	No	No	No	€1,036.21
A	TU 1500-160	16 49/64"	2.93"	10 17/32"	5170 lbf.	36 mm	No	No	No	€1,062.23
A	TU 1500-200	19 57/64"	2.93"	12 3/32"	5170 lbf.	36 mm	No	No	No	€1,123.35
A	TU 1500-250	23 51/64"	2.93"	14 3/64"	5170 lbf.	36 mm	No	No	No	€1,162.91
A	TU 1500-300	27 11/16"	2.93"	15 63/64"	5170 lbf.	36 mm	No	No	No	€1,219.39

ASSOCIATED SPRING RAYMOND -

TU 250 Gas Springs

A

B

Style	Model	Force	Compressed Length	Extended Length	Cylinder Dia.	Rod Dia.	Locking	Fixed Resistance	Adjustable Resistance	Price
A	TU 250-016	600 lbs.	2.62"	3.23"	1 1/2"	-	No	No	No	€371.48
B	TU 250-012	790 lbf.	2 7/16"	2 15/16"	1 1/2"	15 mm	No	No	No	€367.56
A	TU 250-100	790 lbf.	5 27/32"	9 3/4"	1 1/2"	15 mm	No	No	No	€482.63
A	TU 250-019	790 lbf.	2 3/4"	3 29/64"	1 1/2"	15 mm	No	No	No	€364.41
A	TU 250-038	790 lbf.	3 7/16"	4 59/64"	1 1/2"	15 mm	No	No	No	€389.77
B	TU 250-010	790 lbf.	2 11/32"	2 47/64"	1 1/2"	15 mm	No	No	No	€364.15
A	TU 250-125	790 lbf.	6 13/16"	11 45/64"	1 1/2"	15 mm	No	No	No	€501.20
A	TU 250-080	790 lbf.	5 1/16"	8 3/16"	1 1/2"	15 mm	No	No	No	€464.05
B	TU 250-063	790 lbf.	4 27/64"	6 29/32"	1 1/2"	15 mm	No	No	No	€441.83
A	TU 250-025	790 lbf.	2 59/64"	3 29/32"	1 1/2"	15 mm	No	No	No	€386.62
A	TU 250-050	790 lbf.	3 29/32"	5 27/32"	1 1/2"	15 mm	No	No	No	€412.13

Strictly Necessary Cookies

Advertising

Recommendations

Functionality

Analytics

Categories

Brands

ASSOCIATED SPRING RAYMOND Gas Springs And Dampers

Black oxide gas springs with pressurised nitrogen gas to offer a controlled pulling and pushing force. Available in strokes ranging from 6 mm (0.24 inches) to 300 mm (11.8 inches) and forces from 15 lb to 41000 lb

EP2 16 Gas Springs

R12 Gas Springs

Powerline X320 Gas Springs

TM 250 Gas Springs, Metric

TU 750 Gas Springs

TU 7500 Gas Springs

Powerline X1500 Gas Springs

Powerline X170 Gas Springs

Powerline X2400 Gas Springs

Powerline X350 Gas Springs

R19 Gas Springs

Powerline X4200 Gas Springs

Powerline X500 Gas Springs

CU1000 Gas Springs

TI 250 Gas Springs, Inch

M2 Gas Springs

CU1800 Gas Springs

Powerline X750 Gas Springs

TU 10000 Gas Springs

TU 1500 Gas Springs

TU 250 Gas Springs

Popular Search Queries

Explore More

Select your cookie preferences

Strictly Necessary Cookies

Advertising

Recommendations

Functionality

Analytics

Categories

Brands

ASSOCIATED SPRING RAYMOND Gas Springs And Dampers Black oxide gas springs with pressurised nitrogen gas to offer a controlled pulling and pushing force. Available in strokes ranging from 6 mm (0.24 inches) to 300 mm (11.8 inches) and forces from 15 lb to 41000 lb

Popular Search Queries

Explore More

ASSOCIATED SPRING RAYMOND Gas Springs And Dampers

Black oxide gas springs with pressurised nitrogen gas to offer a controlled pulling and pushing force. Available in strokes ranging from 6 mm (0.24 inches) to 300 mm (11.8 inches) and forces from 15 lb to 41000 lb
