What is Con-Sert Tool #8?

Con-Sert #8 tools are designed for fast & easy installation of concrete screws.

What is a drop-in anchor setting tool?

These tools can be used for hanging pipes and anchoring into concrete. Drill a hole in concrete and insert the anchor into the hole that has already been created.

What is a pilot punch and how is it used?

Pilot punches are used as locating tools for progressive dies. The material is transferred to the following station when a punch creates a hole in one station. Before the press cycles the next stroke, the pilot punch inserts itself into the hole and precisely places the material.

How are female threaded drop-in anchors installed?

• Drop-in anchors are employed for overhead applications because the interior plug of the anchor stretches in four directions to keep the anchor securely inside the hole before inserting a threaded rod or bolt.
• To install, set the anchor into the hole, insert the necessary anchor setting tools into the anchor and whack the tool with a hammer until the thicker part of the tool contacts the anchor.
• When necessary, this kind of mechanism enables you to remove the bolt, but it keeps the anchor in place and concealed in concrete.

What are the important points to remember while installing anchors?

• Anchors can be positioned flush with the surface or below the surface's base.
• To support temporary concrete formwork, use anchors that have a coil thread.
• For easy threading with a corresponding rod or bolt, their threads are shallow and widely spaced.
• They are not intended to be used permanently.
